REMOTE SHOCK LIMITER ASSEMBLY для Arctic Cat ZR 600 EFI CC (CC GREEN) - 2002 года выпуска

  • №
    Артикул
    Название
  • -
    0704-646 FRONT ARM COMPLETE ASSEMBLY
    FRONT ARM COMPLETE ASSEMBLY
  • 1
    0704-645 END CAP/ADJUSTER KNOB ASSEMBLY (INC. 2, 8)
    END CAP/ADJUSTER KNOB ASSEMBLY (INC. 2, 8)
  • 2
    0704-647 KNOB, END CAP, ASSEMBLY (INC. 3, 6)
    KNOB, END CAP, ASSEMBLY (INC. 3, 6)
  • 3
    0623-537 PLUG, HOLE
    PLUG, HOLE
  • 4
    1604-526 KNOB, ADJUSTER
    KNOB, ADJUSTER
  • 5
    8042-486 NUT
    NUT
  • 6
    1604-831 STUD
    STUD
  • 7
    0704-602 END CAP
    END CAP
  • 8
    1604-832 NUT, STOP, ADJUSTER KNOB
    NUT, STOP, ADJUSTER KNOB
  • 9
    0623-697 SCREW, RELIEF
    SCREW, RELIEF
  • 10
    0423-182 O-RING
    O-RING
  • 11
    1604-833 PISTON, FLOATING
    PISTON, FLOATING
  • 12
    1604-278 STRAP, PISTON, TEFLON
    STRAP, PISTON, TEFLON
  • 13
    1604-277 O-RING
    O-RING
  • 14
    1604-835 BODY, ADJUSTER, RESERVOIR
    BODY, ADJUSTER, RESERVOIR
  • 15
    1604-836 END CAP, RESERVOIR
    END CAP, RESERVOIR
  • 16
    1604-271 O-RING
    O-RING
  • 17
    1604-531 HOSE, ADJUSTER/COUPLER, 38 IN.
    HOSE, ADJUSTER/COUPLER, 38 IN.
  • 18
    1604-537 COUPLER
    COUPLER
  • 19
    4611-332 DECAL, "ACT", SHOCK
    DECAL, "ACT", SHOCK
  • 20
    1639-245 OIL, GAS SHOCK, 6 QT CASE
    OIL, GAS SHOCK, 6 QT CASE
