FRONT SUSPENSION ASSEMBLY для Arctic Cat HDX 700 XT BLACK [U2016R6T1PISO] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    1603-889 RETAINER, SPRING
    RETAINER, SPRING
  • 2
    0503-469 SPRING, COIL - PAINTED - WHITE
    SPRING, COIL - PAINTED - WHITE
  • 3
    0404-496 CAM, SPRING ADJUSTER
    CAM, SPRING ADJUSTER
  • 4
    0403-511 SHOCK ABSORBER (INC. 5-6)
    SHOCK ABSORBER (INC. 5-6)
  • 5
    8409-055 ...SCREW, CAP
    ...SCREW, CAP
  • 6
    1423-335 ...NUT, LOCK
    ...NUT, LOCK
  • 7
    0503-432 A-ARM, FRONT UPPER - RIGHT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
    A-ARM, FRONT UPPER - RIGHT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
  • 7
    0503-433 A-ARM, FRONT UPPER - LEFT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
    A-ARM, FRONT UPPER - LEFT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
  • 8
    0403-409 ...BUSHING
    ...BUSHING
  • 9
    0403-438 ...COLLAR
    ...COLLAR
  • 10
    0423-009 ...CLIP, BALL JOINT
    ...CLIP, BALL JOINT
  • 11
    0405-483 ...BALL JOINT
    ...BALL JOINT
  • 12
    0423-946 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 13
    1502-594 CLAMP, ROUTING
    CLAMP, ROUTING
  • 14
    8409-075 SCREW, CAP
    SCREW, CAP
  • 15
    0503-376 A-ARM, FRONT LOWER - RIGHT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
    A-ARM, FRONT LOWER - RIGHT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
  • 15
    0503-377 A-ARM, FRONT LOWER - LEFT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
    A-ARM, FRONT LOWER - LEFT - ASSEMBLY (BLACK) (INC FOUR NO. 8, TWO NO. 9, ONE NO. 10 AND ONE NO. 11)
  • 16
    1406-034 GUARD, BOOT - AXLE - RIGHT
    GUARD, BOOT - AXLE - RIGHT
  • 16
    1406-035 GUARD, BOOT - AXLE - LEFT
    GUARD, BOOT - AXLE - LEFT
  • 17
    0423-545 SCREW, SHOULDER
    SCREW, SHOULDER
  • 18
    2502-357 KIT, HALFSHAFT (INC. 19-22)
    KIT, HALFSHAFT (INC. 19-22)
  • 19
    2436-111 REPAIR KIT, BOOT (INC. 20)
    REPAIR KIT, BOOT (INC. 20)
  • 20
    1441-988 CLIP, RETAINING
    CLIP, RETAINING
  • 21
    1402-885 PIN, DETENT
    PIN, DETENT
  • 22
    1402-889 CLIP, RETAINING
    CLIP, RETAINING
  • 23
    0423-998 SCREW, SHOULDER
    SCREW, SHOULDER
  • 24
    0505-580 KNUCKLE, STEERING - ASSEMBLY - RIGHT (INC. ONE NO. 25-26)
    KNUCKLE, STEERING - ASSEMBLY - RIGHT (INC. ONE NO. 25-26)
  • 24
    0505-581 KNUCKLE, STEERING - ASSEMBLY - LEFT (INC. ONE NO. 25-26)
    KNUCKLE, STEERING - ASSEMBLY - LEFT (INC. ONE NO. 25-26)
  • 25
    1402-809 ...BEARING
    ...BEARING
  • 26
    0423-423 ...RING, RETAINING
    ...RING, RETAINING
