CRANKCASE ASSEMBLY для Arctic Cat WILDCAT TRAIL RED [U2015W5T4CUSR] - 2015 года выпуска`
-
№АртикулНазвание
-
13303-386 BOLT, FLANGEBOLT, FLANGE
-
23304-649 SCREW, CAPSCREW, CAP
-
33307-053 BOLT, FLANGEBOLT, FLANGE
-
43306-927 SCREW, CAPSCREW, CAP
-
53306-926 SCREW, CAPSCREW, CAP
-
63306-924 LOCK, PIN OILLOCK, PIN OIL
-
73301-716 PIN, DOWELPIN, DOWEL
-
80812-034 FILTER, OILFILTER, OIL
-
90812-066 UNION, OIL FILTERUNION, OIL FILTER
-
103306-920 SWITCH, OIL PRESSURESWITCH, OIL PRESSURE
-
110806-029 STICK, OIL LEVEL (INC. 12)STICK, OIL LEVEL (INC. 12)
-
123304-102 ...O-RING...O-RING
-
133306-923 WASHERWASHER
-
140413-359 FITTING1/2" HOSE-3 BARB-M14X1.25FITTING1/2" HOSE-3 BARB-M14X1.25
-
153306-969 CRANKCASE ASSEMBLYCRANKCASE ASSEMBLY
