SEAT ASSEMBLY для Arctic Cat PROWLER 1000 XT RED [U2015R4W1PUSR] - 2015 года выпуска

  • №
    Артикул
    Название
  • 1
    5506-623 PANEL, SEAT - ASSEMBLY (INC. 2-7 AND FIVE NO. 8)
    PANEL, SEAT - ASSEMBLY (INC. 2-7 AND FIVE NO. 8)
  • 2
    0623-544 ...PLUG
    ...PLUG
  • 3
    4406-320 ...PANEL, SEAT - FRONT - RIGHT
    ...PANEL, SEAT - FRONT - RIGHT
  • 3
    4406-321 ...PANEL, SEAT - FRONT - LEFT
    ...PANEL, SEAT - FRONT - LEFT
  • 4
    2406-912 ...PANEL, SEAT - REAR - RIGHT
    ...PANEL, SEAT - REAR - RIGHT
  • 4
    2406-913 ...PANEL, SEAT - REAR - LEFT
    ...PANEL, SEAT - REAR - LEFT
  • 5
    2406-915 ...SEAL, CARGO BOX
    ...SEAL, CARGO BOX
  • 6
    8476-620 ...SCREW, MACHINE
    ...SCREW, MACHINE
  • 7
    0412-783 ...FOIL, PROTECTIVE
    ...FOIL, PROTECTIVE
  • 8
    0423-577 ...CLIP, U-NUT
    ...CLIP, U-NUT
  • 9
    0623-784 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 10
    0423-609 SCREW, MACHINE
    SCREW, MACHINE
  • 11
    2406-910 BASE, SEAT - RIGHT
    BASE, SEAT - RIGHT
  • 11
    2406-911 BASE, SEAT - LEFT
    BASE, SEAT - LEFT
  • 12
    2416-091 COVER, ACCESS - AIR FILTER
    COVER, ACCESS - AIR FILTER
  • 13
    0412-560 FOIL, PROTECTIVE OPTIONAL
    FOIL, PROTECTIVE OPTIONAL
  • 14
    1423-182 SCREW, CAP
    SCREW, CAP
  • 15
    5506-888 BELT, SEAT
    BELT, SEAT
  • 16
    7506-213 BRACKET, SEAT BELT RETRACTOR
    BRACKET, SEAT BELT RETRACTOR
  • 17
    1423-184 NUT, LOCK
    NUT, LOCK
  • 18
    1506-925 SEAT, LOW-BACK
    SEAT, LOW-BACK
  • 19
    8468-620 SCREW, MACHINE
    SCREW, MACHINE
  • 20
    2506-780 PLATE, SEAT BASE
    PLATE, SEAT BASE
  • 21
    0406-877 BUMPER
    BUMPER
  • 22
    8468-820 SCREW, MACHINE
    SCREW, MACHINE
  • 23
    1423-254 STUD, LATCH - SEAT
    STUD, LATCH - SEAT
  • 24
    2706-164 LATCH, SEAT - ASSEMBLY (INC. 25)
    LATCH, SEAT - ASSEMBLY (INC. 25)
  • 25
    2606-854 ...LEVER, SEAT LATCH
    ...LEVER, SEAT LATCH
  • 26
    0623-038 NUT W/WASHER
    NUT W/WASHER
  • 27
    8424-002 NUT
    NUT
