RIGHT CRANKCASE AND COVER ASSEMBLY для Arctic Cat 150 YOUTH RED [A2010KYC2BUSR] - 2010 года выпуска`
-
№АртикулНазвание
-
13303-381 SCREW, CAPSCREW, CAP
-
23305-918 CAP, CRANKCASE COVER - ASSEMBLYCAP, CRANKCASE COVER - ASSEMBLY
-
33304-971 O RING 26.5*2.0O RING 26.5*2.0
-
43304-596 O-RING 23X2.4O-RING 23X2.4
-
53304-012 CAP, INSPECTIONCAP, INSPECTION
-
63304-099 O-RING 13.8*2.5O-RING 13.8*2.5
-
73304-963 COVER, CRANKCASE (INC. ONE NO. 8)COVER, CRANKCASE (INC. ONE NO. 8)
-
83304-065 ...PLUG...PLUG
-
93304-192 SCREW, CAPSCREW, CAP
-
103303-387 SCREW, CAPSCREW, CAP
-
113303-050 GAUGE, OIL LEVEL (INC. 12)GAUGE, OIL LEVEL (INC. 12)
-
123304-102 ...O-RING 18*3...O-RING 18*3
-
133303-342 PIN DOWEL 10*16PIN DOWEL 10*16
-
143304-964 GASKETGASKET
-
153304-965 ROTOR/FLYWHEELROTOR/FLYWHEEL
-
163304-113 SCREW, MACHINESCREW, MACHINE
-
173304-967 STATOR COMPSTATOR COMP
-
183304-118 SCREW, MACHINESCREW, MACHINE
-
193304-190 SCREW, CAPSCREW, CAP
-
203304-904 SCREW, CAPSCREW, CAP
-
213303-344 RING, RETAININGRING, RETAINING
-
223304-903 SCREW, CAPSCREW, CAP
-
233304-514 RING, RETAININGRING, RETAINING
-
243304-889 HOSE, VENT (INC. 25)HOSE, VENT (INC. 25)
-
253304-433 ...CLAMP, HOSE...CLAMP, HOSE
-
263304-008 BOLT, STUDBOLT, STUD
-
273304-195 BEARING RADIAL BALL 6205BEARING RADIAL BALL 6205
-
283304-081 OIL SEAL 14*28*7OIL SEAL 14*28*7
-
293304-972 CLAMP, ROUTINGCLAMP, ROUTING
-
303304-884 CRANKCASE - RIGHT (INC. ONE NO. 8)CRANKCASE - RIGHT (INC. ONE NO. 8)
-
313304-699 BEARING BALL RADIAL 6204BEARING BALL RADIAL 6204
-
323304-909 BEARING BALL RADIAL 6302BEARING BALL RADIAL 6302
-
333304-898 BEARING NEEDLE 30*42*17BEARING NEEDLE 30*42*17
-
343304-425 OIL SEAL 24.8*52.2*7OIL SEAL 24.8*52.2*7
-
353304-887 GASKET, CRANKCASEGASKET, CRANKCASE
