WINCH ASSEMBLY для Arctic Cat 500 H1 TRV (RED) [A2009TBO4EUSR] - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    1441-704 WINCH (INC. 2-3)
    WINCH (INC. 2-3)
  • 2
    0441-061 ...CABLE, WINCH
    ...CABLE, WINCH
  • 3
    1411-826 ...DECAL, WARNING
    ...DECAL, WARNING
  • 4
    8051-246 WASHER, LOCK
    WASHER, LOCK
  • 5
    8408-820 SCREW, CAP
    SCREW, CAP
  • 6
    0541-759 HOOK, WINCH W/STRAP - ASSEMBLY (INC. 7-9)
    HOOK, WINCH W/STRAP - ASSEMBLY (INC. 7-9)
  • 7
    0541-760 ...HOOK, WINCH W/STRAP
    ...HOOK, WINCH W/STRAP
  • 8
    1441-130 ...PIN
    ...PIN
  • 9
    1441-129 ...PIN, COTTER
    ...PIN, COTTER
  • 10
    0441-403 ROLLER, WINCH
    ROLLER, WINCH
  • 11
    8468-820 SCREW, MACH-TSPNH M8X1.25X20 CL8.8 BLK
    SCREW, MACH-TSPNH M8X1.25X20 CL8.8 BLK
  • 12
    0123-788 TIE, CABLE - 8 IN.
    TIE, CABLE - 8 IN.
  • 13
    0445-068 CABLE, WINCH/SOLENOID (7" YELLOW)
    CABLE, WINCH/SOLENOID (7" YELLOW)
  • 14
    0445-069 CABLE, WINCH/SOLENOID (10" BLUE)
    CABLE, WINCH/SOLENOID (10" BLUE)
  • 15
    0623-038 NUT W/WASHER
    NUT W/WASHER
  • 16
    1441-112 CABLE, SOLENOID/BATTERY - BLACK
    CABLE, SOLENOID/BATTERY - BLACK
  • 17
    1441-113 CABLE, SOLENOID/BATTERY - RED
    CABLE, SOLENOID/BATTERY - RED
  • 18
    0441-060 BOOT, TERMINAL
    BOOT, TERMINAL
  • 19
    0409-066 SOLENOID
    SOLENOID
  • 20
    8476-625 SCREW, MACHINE
    SCREW, MACHINE
  • 21
    0409-087 SWITCH, CONTROL
    SWITCH, CONTROL
  • 22
    0409-034 RETAINER, CONTROL SWITCH
    RETAINER, CONTROL SWITCH
  • 23
    0409-106 COVER, SWITCH
    COVER, SWITCH
  • 24
    0423-593 WASHER
    WASHER
  • 25
    0423-382 SCREW, SELF-TAPPING
    SCREW, SELF-TAPPING
  • 26
    8464-560 SCREW, MACHINE
    SCREW, MACHINE
