BUMPER - FRONT AND REAR для Yamaha SRVIPER L TX LE - 2017 года выпуска`
-
№АртикулНазвание
-
18JP-F8441-20-00 SADDLE BAG 1SADDLE BAG 1
-
28JP-RA516-00-00 RIVET, 7RIVET, 7
-
38JP-F8423-00-00 STAY, SIDE BAGSTAY, SIDE BAG
-
48JP-RA524-00-00 RIVET, 15RIVET, 15
-
58JP-K7595-00-00 FLAPFLAP
-
68JY-K7541-20-00 BUMPER, REAR 1BUMPER, REAR 1
-
78JP-RA520-10-00 RIVET, 11RIVET, 11
-
88KP-K7594-00-00 PLATE, FLAP 2PLATE, FLAP 2
-
98KP-K7593-00-00 PLATE, FLAP 1PLATE, FLAP 1
-
108JM-RA322-00-00 NUT, FLANGE M6-1.0NUT, FLANGE M6-1.0
-
118JP-RA260-00-00 SCREW, M6X1.0X20SCREW, M6X1.0X20
-
128JP-RA527-00-00 RIVET, 3/16RIVET, 3/16
