BUMPER - FRONT AND REAR для Yamaha SRVIPER L TX DX - 2015 года выпуска`
-
№АртикулНазвание
-
18JP-RA516-00-00 RIVET, 7RIVET, 7
-
28JP-F8441-10-00 SADDLE BAG 1SADDLE BAG 1
-
38JP-F8423-00-00 STAY, SIDE BAGSTAY, SIDE BAG
-
48JP-RA524-00-00 RIVET, 15RIVET, 15
-
58JP-K7595-00-00 FLAPFLAP
-
68JX-K7541-20-00 BUMPER, REAR 1 (VRC1 - VIVID RED)BUMPER, REAR 1 (VRC1 - VIVID RED)
-
68JX-K7541-10-00 BUMPER, REAR 1 (YB - YAMAHA BLACK)BUMPER, REAR 1 (YB - YAMAHA BLACK)
-
78JP-RA260-00-00 SCREW, M6X1.0X20SCREW, M6X1.0X20
-
88JM-RA322-00-00 NUT, FLANGE M6-1.0NUT, FLANGE M6-1.0
-
98JP-RA518-00-00 RIVET, 9RIVET, 9
