CONSOLE ASSY для Yamaha RAGE GT - 2007 года выпуска`
-
№АртикулНазвание
-
18FA-77711-00-P1 PANEL, INSTRUMENT (DPBMC)PANEL, INSTRUMENT (DPBMC)
-
18FA-77711-10-33 PANEL, INSTRUMENT (YB)PANEL, INSTRUMENT (YB)
-
28FA-77746-00-00 GROMMETGROMMET
-
34N0-27114-00-00 STOPPER, MAIN STANDSTOPPER, MAIN STAND
-
48FA-77131-00-00 LOUVER 1LOUVER 1
-
58FA-77132-00-00 LOUVER 2LOUVER 2
-
690154-06009-00 SCREW, BINDINGSCREW, BINDING
-
790149-06263-00 SCREW, SPEC'L SHAPESCREW, SPEC'L SHAPE
-
890183-06100-00 NUT, SPRINGNUT, SPRING
-
98FA-77171-00-00 BODY, LATCH 1BODY, LATCH 1
-
1090480-16278-00 GROMMETGROMMET
-
115JW-2413B-00-00 EMBLEMEMBLEM
-
128FA-77737-00-00 TRIM, INSTRUMENT PANEL 1TRIM, INSTRUMENT PANEL 1
