SUSPENSION - TORQUE ARM ASSY для Yamaha PHAZER - 2007 года выпуска`
-
№АртикулНазвание
-
18GC-47331-00-00 ARM, PIVOT 1ARM, PIVOT 1
-
28GC-47465-00-00 SHAFT 1SHAFT 1
-
390386-22001-00 BUSHBUSH
-
490105-103A1-00 BOLT, WASHER BASEDBOLT, WASHER BASED
-
58GC-47486-00-00 SHAFT 4SHAFT 4
-
690386-20001-00 BUSHBUSH
-
790201-10626-00 WASHER, PLATEWASHER, PLATE
-
890105-10209-00 BOLT, FLANGEBOLT, FLANGE
-
98ES-47485-00-00 SHAFT 3SHAFT 3
-
1090105-10209-00 BOLT, FLANGEBOLT, FLANGE
-
118GC-47495-00-00 STOPPER 1STOPPER 1
-
1297002-06025-00 BOLTBOLT
-
1390201-06036-00 WASHER, PLATEWASHER, PLATE
-
1495702-06300-00 NUT, NYLONNUT, NYLON
-
158GC-47481-00-00 SHOCK ABSORBER 2SHOCK ABSORBER 2
