HANDLEBAR - CABLES AND GRIPS для Yamaha PHAZER - 2007 года выпуска`
-
№АртикулНазвание
-
18GC-26311-00-00 CABLE, THROTTLE 1CABLE, THROTTLE 1
-
28GC-26314-00-00 SPRINGSPRING
-
38GC-26240-00-00 GRIP ASSYGRIP ASSY
-
490267-48014-00 RIVET, BLINDRIVET, BLIND
-
58FP-82351-00-00 TUBE, CORDTUBE, CORD
-
68GC-82351-00-00 TUBE, CORDTUBE, CORD
