FENDER - FRONT / REAR для Yamaha V STAR 950 TOURER - 2014 года выпуска`
-
№АртикулНазвание
-
15S7-21510-01-P0 FRONT FENDER COMP. (SMX)FRONT FENDER COMP. (SMX)
-
295812-08020-00 BOLT, FLANGEBOLT, FLANGE
-
35S7-21587-00-00 STAY 1STAY 1
-
45S7-21588-00-00 STAY 2STAY 2
-
53D8-21597-00-00 HOLDER, WIRE 1HOLDER, WIRE 1
-
695027-06010-00 BOLT, FLANGEBOLT, FLANGE
-
711H-85110-01-00 REFLECTOR ASSYREFLECTOR ASSY
-
895707-05500-00 NUT FLANGE 3GM (BLACK)NUT FLANGE 3GM (BLACK)
-
95S7-W2161-21-P0 REAR FENDER COMP. (SMX)REAR FENDER COMP. (SMX)
-
105PX-21669-01-00 ...SEAL...SEAL
-
115S7-21669-00-00 ...SEAL...SEAL
-
121D6-2153E-00-00 ...EMBLEM, YAMAHA...EMBLEM, YAMAHA
-
1326S-2165A-00-00 ......GRAPHIC SET, REAR FENDER......GRAPHIC SET, REAR FENDER
-
1490480-13027-00 GROMMETGROMMET
-
155S7-21629-00-P0 GUARD, MUD (SMX)GUARD, MUD (SMX)
-
165S7-21638-00-00 DAMPER 1DAMPER 1
-
175S7-21639-00-00 DAMPER 2DAMPER 2
-
1890269-07077-00 RIVETRIVET
-
195S7-2162R-00-00 FENDER 2FENDER 2
-
2092012-06012-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
2195602-06200-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
2290387-07717-00 COLLARCOLLAR
-
234DN-21669-00-00 SEALSEAL
-
245RU-21686-00-00 PLATE, ROUTING 2 (CALIF ONLY)PLATE, ROUTING 2 (CALIF ONLY)
-
2534B-21684-00-00 PLATE, ROUTING (CALIF ONLY)PLATE, ROUTING (CALIF ONLY)
