FENDER - FRONT / REAR для Yamaha ROAD STAR SILVERADO - 2010 года выпуска`
-
№АртикулНазвание
-
15VN-YK215-00-P6 FRONT FENDER COMP. (BWC1)FRONT FENDER COMP. (BWC1)
-
291314-08025-00 BOLT, HEXAGON SOCKET HEADBOLT, HEXAGON SOCKET HEAD
-
35VN-Y2161-R0-P0 REAR FENDER COMP. (BWC1)REAR FENDER COMP. (BWC1)
-
45VR-2165A-20-00 GRAPHIC SET,REAR FENDERGRAPHIC SET,REAR FENDER
-
51D6-2153E-00-00 EMBLEM, YAMAHAEMBLEM, YAMAHA
-
65GA-2164A-00-00 GRIP 1GRIP 1
-
75GA-2164E-00-00 GRIP 2GRIP 2
-
85GA-2164F-00-00 STAY 1STAY 1
-
995024-08012-00 BOLT, FLG.(SMALL HEAD)BOLT, FLG.(SMALL HEAD)
-
105GA-2840F-30-00 BACK REST ASSYBACK REST ASSY
-
115GA-2164G-00-00 STAY 2STAY 2
-
1295024-06010-00 BOLT, FLG.(SMALL HEAD)BOLT, FLG.(SMALL HEAD)
-
135GA-24786-01-00 EMBLEMEMBLEM
-
1490119-06056-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
154WM-21649-00-00 DAMPERDAMPER
-
164WM-21638-00-00 DAMPER 1DAMPER 1
-
1790480-01015-00 GROMMETGROMMET
-
185VN-21735-00-00 SEAL 2SEAL 2
-
195VN-21643-00-00 STAY, REARSTAY, REAR
-
2090105-06048-00 BOLT, FLANGEBOLT, FLANGE
-
214WM-21629-00-P8 GUARD, MUD (BWC1)GUARD, MUD (BWC1)
-
2290119-06226-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
235VN-21639-10-00 DAMPER 2DAMPER 2
-
245PW-23472-00-00 PROTECTORPROTECTOR
-
254U5-2317J-00-00 DAMPER 1DAMPER 1
