ELECTRICAL 2 для Yamaha YZF-R1 - 2008 года выпуска`
-
№АртикулНазвание
-
11D0-81940-02-00 STARTER RELAY ASSYSTARTER RELAY ASSY
-
236Y-82151-00-00 ...FUSE (15A-BL)...FUSE (15A-BL)
-
35PS-82576-01-00 LEAN ANGLE SENSORLEAN ANGLE SENSOR
-
491312-04025-00 BOLTBOLT
-
590201-047A2-00 WASHER, PLATEWASHER, PLATE
-
690183-04039-00 NUT, SPRINGNUT, SPRING
-
75VK-81950-30-00 RELAY ASSYRELAY ASSY
-
84C8-83350-10-00 FLASHER RELAY ASSYFLASHER RELAY ASSY
-
990109-080G5-00 BOLTBOLT
-
104TH-83371-00-00 HORNHORN
-
1195807-06012-00 BOLT, FLANGEBOLT, FLANGE
-
1213S-82566-50-00 SWITCH, SIDE STANDSWITCH, SIDE STAND
-
134C8-27463-00-00 COVER 2COVER 2
-
144C8-2175P-00-00 SEAT 4SEAT 4
-
1592017-05035-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
1695607-05200-00 NUT, U FLANGENUT, U FLANGE
-
1790387-05025-00 COLLARCOLLAR
-
184C8-82530-00-00 STOP SWITCH ASSYSTOP SWITCH ASSY
-
1990465-10098-00 BANDBAND
-
205JJ-81950-20-00 RELAY ASSYRELAY ASSY
-
215JJ-81952-00-00 ...HOLDER, RELAY...HOLDER, RELAY
-
224C8-8591A-60-00 ENGINE CONTROL UNIT ASSYENGINE CONTROL UNIT ASSY
-
234C8-82501-10-00 MAIN SWITCH STEERING LOCKMAIN SWITCH STEERING LOCK
-
244BH-82511-09-00 BLANK KEYBLANK KEY
-
2595027-06008-00 BOLT, FLANGEBOLT, FLANGE
-
26BTY-YTZ10-S0-00 BATTERY ASSY (YUASA YTZ10S)BATTERY ASSY (YUASA YTZ10S)
-
274C8-82590-40-00 WIRE HARNESS ASSYWIRE HARNESS ASSY
-
285JJ-82151-70-00 ...FUSE (25A-BL)...FUSE (25A-BL)
-
295JJ-82151-10-00 ...FUSE (15A-BL)...FUSE (15A-BL)
-
305JJ-82151-00-00 ...FUSE (7.5A-BL)...FUSE (7.5A-BL)
-
315JW-82151-10-00 ...FUSE (50A)...FUSE (50A)
-
325EA-81950-20-00 RELAY ASSYRELAY ASSY
-
335EA-81952-00-00 ...HOLDER, RELAY...HOLDER, RELAY
-
341D7-81960-00-00 RECTIFIER & REGULATOR ASSYRECTIFIER & REGULATOR ASSY
-
3595802-06025-00 BOLT, FLANGEBOLT, FLANGE
-
3690202-05187-00 WASHER, PLATEWASHER, PLATE
-
3790464-15195-00 CLAMPCLAMP
-
3890464-15195-00 CLAMPCLAMP
-
3990464-13077-00 CLAMPCLAMP
-
4090465-10098-00 BANDBAND
-
411UA-82591-00-00 BANDBAND
-
421UA-82591-00-00 BANDBAND
-
434C8-82171-00-00 STAY, FUSE BOXSTAY, FUSE BOX
-
4490387-06040-00 COLLARCOLLAR
-
4590119-06228-00 BOLT, WITH WASHERBOLT, WITH WASHER
-
4690464-13077-00 CLAMPCLAMP
-
4790464-13073-00 CLAMPCLAMP
-
4890464-13073-00 CLAMPCLAMP
-
494C8-82116-00-00 WIRE, MINUS LEADWIRE, MINUS LEAD
