ELECTRICAL 2 для Yamaha FJR1300A (3PP6B) [FJR13AWC] - 2007 года выпуска
-
№АртикулНазвание
-
15EA-82100-11-00 BATTERY ASSY (GS GT14B-4)BATTERY ASSY (GS GT14B-4)
-
23P6-82115-00-00 WIRE, PLUS LEADWIRE, PLUS LEAD
-
33P6-82116-00-00 WIRE, MINUS LEADWIRE, MINUS LEAD
-
44YR-81940-02-00 STARTER RELAY ASSY (RC19-018)STARTER RELAY ASSY (RC19-018)
-
51AE-82151-00-00 ...FUSE (30A-BL)...FUSE (30A-BL)
-
695022-06008-00 BOLT, FLANGEBOLT, FLANGE
-
73P6-82590-10-00 WIRE HARNESS ASSYWIRE HARNESS ASSY
-
85JJ-82151-50-00 ...FUSE (3A-BL)...FUSE (3A-BL)
-
95JJ-82151-30-00 ...FUSE (10A-BL)...FUSE (10A-BL)
-
105JJ-82151-10-00 ...FUSE (15A-BL)...FUSE (15A-BL)
-
115JJ-82151-70-00 ...FUSE (25A-BL)...FUSE (25A-BL)
-
125JW-82151-10-00 ...FUSE (50A)...FUSE (50A)
-
1390465-10098-00 CLAMPCLAMP
-
1490464-16006-00 CLAMPCLAMP
-
1590465-13152-00 CLAMPCLAMP
-
161UA-82591-00-00 BANDBAND
-
1790465-13275-00 CLAMPCLAMP
-
185Y9-12491-00-00 CLAMP 1CLAMP 1
-
191D7-81960-00-00 RECTIFIER & REGULATOR ASSYRECTIFIER & REGULATOR ASSY
-
203P6-81975-00-00 PLATE, RECTIFIER FITTINGPLATE, RECTIFIER FITTING
-
2195602-06200-00 NUT, SELF-LOCKINGNUT, SELF-LOCKING
-
225VK-81950-30-00 RELAY ASSY (5VK-30)RELAY ASSY (5VK-30)
-
2390465-10098-00 CLAMPCLAMP
-
245EA-81950-20-00 RELAY ASSY (5EA-02)RELAY ASSY (5EA-02)
-
255EA-81952-00-00 ...HOLDER, RELAY...HOLDER, RELAY
-
265JJ-81950-10-00 RELAY ASSY (G8HN-1C4T-DJ-Y51)RELAY ASSY (G8HN-1C4T-DJ-Y51)
-
275DM-81950-00-00 RELAY ASSY (G8HN-1C4T-DJ-Y52)RELAY ASSY (G8HN-1C4T-DJ-Y52)
-
283P6-82530-00-00 STOP SWITCH ASSYSTOP SWITCH ASSY
-
295JW-2144G-00-00 STAY, STOP SWITCHSTAY, STOP SWITCH
-
3098902-05008-00 SCREW, BINDSCREW, BIND
-
315PS-82576-01-00 EMERGENCY STOP SWITCHEMERGENCY STOP SWITCH
-
3298902-04020-00 SCREW, BINDSCREW, BIND
-
3390201-047A2-00 WASHER, PLATEWASHER, PLATE
-
3490464-12036-00 CLAMPCLAMP
-
3590465-13152-00 CLAMPCLAMP
-
365PX-82566-51-00 SWITCH, SIDE STANDSWITCH, SIDE STAND
-
373P6-82388-00-00 PLATEPLATE
-
383P6-82176-00-00 DAMPERDAMPER
-
3990157-05008-00 SCREW, PAN HEADSCREW, PAN HEAD
-
403P6-8254B-00-00 TERMINAL COMP.TERMINAL COMP.
-
415RU-85700-00-00 THERMISTOR ASSYTHERMISTOR ASSY
-
4290464-24001-00 CLAMPCLAMP
-
4390465-10098-00 CLAMPCLAMP
-
445PS-83371-00-00 HORNHORN
-
453P6-83371-00-00 HORNHORN
-
4692012-06012-00 BOLT, BUTTON HEADBOLT, BUTTON HEAD
-
473GM-83350-01-00 FLASHER RELAY ASSYFLASHER RELAY ASSY
-
483Y6-85130-02-00 REAR REFLECTOR ASSYREAR REFLECTOR ASSY
-
4995602-05100-00 NUT, UNUT, U
-
5090201-05725-00 WASHER, PLATEWASHER, PLATE
-
5111H-85110-01-00 REFLECTOR ASSYREFLECTOR ASSY
-
5295702-05500-00 NUT, FLANGENUT, FLANGE
-
533P6-85112-00-00 BRACKET, REFLECTOR 1BRACKET, REFLECTOR 1
-
543P6-85122-00-00 BRACKET, REFLECTOR 2BRACKET, REFLECTOR 2
-
55449-85131-02-00 REFLECTOR, REAR 1REFLECTOR, REAR 1
-
565JW-84751-00-00 BRACKET, LICENSEBRACKET, LICENSE
-
5790201-06778-00 WASHER, PLATEWASHER, PLATE
-
5895602-06100-00 NUT, UNUT, U
-
5990201-05036-00 WASHER, PLATEWASHER, PLATE
