BRAKE - REAR CALIPER для Yamaha RAPTOR 90 - 2016 года выпуска`
-
№АртикулНазвание
-
1BD3-F5311-00-00 HUB, REARHUB, REAR
-
2BD3-F5317-00-00 SPACER, BEARINGSPACER, BEARING
-
3BD3-F53N4-00-00 BEARINGBEARING
-
4BD3-F537Y-00-00 SEAL, DUSTSEAL, DUST
-
5BD3-F5321-00-00 PLATE, BRAKE SHOEPLATE, BRAKE SHOE
-
6BD3-F7217-00-00 BOLTBOLT
-
7BD3-F518E-00-00 SHAFTSHAFT
-
8BD3-F2143-00-00 NUTNUT
-
9BD3-F5319-00-00 SEAL, HUB DUSTSEAL, HUB DUST
-
10BD3-F5351-00-00 CAMSHAFTCAMSHAFT
-
11BD3-F5355-00-00 LEVER, CAMSHAFTLEVER, CAMSHAFT
-
12BD3-F3767-00-00 BOLTBOLT
-
13BD3-F530K-00-00 BRAKE SHOE SETBRAKE SHOE SET
-
14BD3-F6304-00-00 SPRINGSPRING
-
15BD3-F6343-00-00 NUT, ADJUSTINGNUT, ADJUSTING
-
16BD3-F6341-00-00 WIRE, BRAKE 1WIRE, BRAKE 1
-
17BD3-F7438-00-00 PIN, CLEVISPIN, CLEVIS
-
18BD3-F3458-00-00 WASHERWASHER
-
19BD3-F531E-00-00 DRUM, BRAKEDRUM, BRAKE
-
20BD3-F5336-00-00 RING 2RING 2
-
21BD3-F4477-00-00 NUTNUT
-
22BD3-F8374-00-00 BOLT, COWLINGBOLT, COWLING
-
23BD3-F5333-00-00 SPRING, RETURNSPRING, RETURN
-
24BD3-F2312-00-00 CASE, CHAIN 2CASE, CHAIN 2
-
25BD3-F7416-00-00 BOLT, FOOTRESTBOLT, FOOTREST
