HANDLEBAR W/ SWITCHES - LEVERS для Yamaha BASHEE YFZ350R (5FKJ) - 2003 года выпуска
-
№АртикулНазвание
-
15FK-83975-00-00 SWITCH, HANDLE 2SWITCH, HANDLE 2
-
2437-83936-01-00 BAND, SWITCH CORDBAND, SWITCH CORD
-
33GG-82910-10-00 LEVER HOLDER ASSY (LEFT)LEVER HOLDER ASSY (LEFT)
-
44KB-82911-00-00 ...HOLDER, LEVER 1...HOLDER, LEVER 1
-
55LP-83912-00-00 ...LEVER 1...LEVER 1
-
61UY-83922-01-00 ...LEVER 2...LEVER 2
-
74KB-W8393-00-00 ...LOCK, LEVER ASSY...LOCK, LEVER ASSY
-
81UY-83935-00-00 ...COVER...COVER
-
91UY-83909-00-00 ...WASHER, SPECIAL...WASHER, SPECIAL
-
101UY-83967-00-00 ...PIN, LOCK 1...PIN, LOCK 1
-
111UY-83913-00-00 ...COLLAR, LEVER 1...COLLAR, LEVER 1
-
121UY-83966-00-00 ...SPRING, RETURN...SPRING, RETURN
-
131UY-83962-00-00 ...SPRING...SPRING
-
142XJ-82913-00-00 ...HOLDER, LEVER LOWER 1...HOLDER, LEVER LOWER 1
-
1590109-06576-00 ...BOLT...BOLT
-
1695607-06100-00 ...NUT, U...NUT, U
-
1797027-06025-00 ...BOLT...BOLT
-
1892907-06600-00 ...WASHER, PLATE...WASHER, PLATE
-
1998507-05010-00 ...SCREW...SCREW
-
2092907-05600-00 ...WASHER, PLATE...WASHER, PLATE
-
2198507-03008-00 ...SCREW...SCREW
-
2292907-03600-00 ...WASHER...WASHER
-
2397007-06040-00 ...BOLT...BOLT
-
2491690-40022-00 ...PIN, SPRING...PIN, SPRING
-
2590201-082A9-00 ...WASHER, PLATE...WASHER, PLATE
-
2692907-06200-00 ...WASHER...WASHER
-
271UY-83956-00-00 ...CAP 1...CAP 1
-
2890338-12192-00 ...PLUG...PLUG
-
2990123-08046-00 ...BOLT...BOLT
-
3090179-08148-00 ...NUT...NUT
-
314KB-82917-00-00 ...SWITCH...SWITCH
