CARBURETOR для Tohatsu M2.5A2 - 2021 года выпуска`
-
№АртикулНазвание
-
13D5-03100-5 CARBURETOR ASSY
Mark C6CARBURETOR ASSY
Mark C6 -
2309-03170-0 * THROTTLE WIRE ASSY* THROTTLE WIRE ASSY
-
3309-03178-0 * SCREW* SCREW
-
4309-03173-0 * THROTTLE LEVER HOLDER* THROTTLE LEVER HOLDER
-
5309-03101-0 * CARBURETOR BODY CAP* CARBURETOR BODY CAP
-
6309-03107-0 * THROTTLE VALVE SPRING* THROTTLE VALVE SPRING
-
7309-03108-0 * SPRING RECEIVER* SPRING RECEIVER
-
8309-03154-0 * JET NEEDLE CLIP* JET NEEDLE CLIP
-
93F0-03153-3 * JET NEEDLE (#256)* JET NEEDLE (#256)
-
103D5-03106-0 * THROTTLE VALVE* THROTTLE VALVE
-
11309-03155-2 * NEEDLE JET* NEEDLE JET
-
12309-03121-0 * FLOAT CHAMBER GASKET* FLOAT CHAMBER GASKET
-
13309-03125-0 * FLOAT* FLOAT
-
14309-03120-0 * FLOAT CHAMBER* FLOAT CHAMBER
-
15309-03192-0 * DRAIN SCREW* DRAIN SCREW
-
16309-03193-0 * GASKET* GASKET
-
17309-03151-3 * MAIN JET (#86)* MAIN JET (#86)
-
18309-03126-0 * FLOAT ARM PIN* FLOAT ARM PIN
-
19309-03127-1 * FLOAT HINGE* FLOAT HINGE
-
20309-03147-1 * FLOAT VALVE* FLOAT VALVE
-
21309-03148-1 * NEEDLE VALVE SEAT* NEEDLE VALVE SEAT
-
22309-03156-0 * ADJUST SCREW* ADJUST SCREW
-
23309-03157-0 * SPRING* SPRING
-
24309-03161-0 * CHOKE PLATE* CHOKE PLATE
-
25332-03104-0 * CHOKE PLATE NUT* CHOKE PLATE NUT
-
26941303-0600 * SPRING WASHER* SPRING WASHER
-
27309-03163-0 * SHUTTER BOLT* SHUTTER BOLT
-
28309-03164-0 * SHUTTER LEVER* SHUTTER LEVER
-
29309-03113-0 * CARBURETOR BODY BAND* CARBURETOR BODY BAND
-
30309-03114-0 * CARBURETOR BODY BAND BOLT* CARBURETOR BODY BAND BOLT
-
31921532-6410 * SCREW* SCREW
-
32921532-0510 * SCREW* SCREW
-
33309-03177-0 * THROTTLE LEVER WASHER* THROTTLE LEVER WASHER
-
34309-03175-0 * THROTTLE LEVER GASKET* THROTTLE LEVER GASKET
-
35309-03176-1 * THROTTLE LEVER END* THROTTLE LEVER END
-
36309-03174-1 * THROTTLE LEVER COLLAR* THROTTLE LEVER COLLAR
-
37309-03172-1 * THROTTLE LEVER* THROTTLE LEVER
-
38309-03116-2 * O-RING 2.4-15.7* O-RING 2.4-15.7
-
39309-03401-0 KNOBKNOB
-
40921603-0305 SCREWSCREW
-
41314B02496-3 CARBURETOR COVER W/DECALCARBURETOR COVER W/DECAL
-
42921603-0435 SCREWSCREW
