ASSEMBLY KIT PARTS для Tohatsu M5B - 2019 года выпуска`
-
№АртикулНазвание
-
1369Q87301-5 LOWER UNIT ASSY (S)
for Transom "S"LOWER UNIT ASSY (S)
for Transom "S" -
1369Q87302-5 LOWER UNIT ASSY (L)
for Transom "L"LOWER UNIT ASSY (L)
for Transom "L" -
1369Q87304-3 LOWER UNIT ASSY (UL)
for Transom "UL"LOWER UNIT ASSY (UL)
for Transom "UL" -
2369Q87314-4 EXTENSION HOUSING KIT (UL)
for Transom "L"⇒"UL"EXTENSION HOUSING KIT (UL)
for Transom "L"⇒"UL" -
2369Q61110-2 * EXTENSION HOUSING* EXTENSION HOUSING
-
29161E3-0625 * BOLT* BOLT
-
29401E3-0600 * WASHER* WASHER
-
29401E3-0800 * WASHER* WASHER
-
2930103-0800 * NUT* NUT
-
29152E3-0825 * STUD* STUD
-
2369-64303-0 * DRIVE SHAFT ASSY (UL)* DRIVE SHAFT ASSY (UL)
-
2369-65120-0 * WATER PIPE ASSY (UL)* WATER PIPE ASSY (UL)
-
2369-66014-2 * CAM ROD (UL)* CAM ROD (UL)
-
3369B87090-5 ENGINE SHORT BLOCK KITENGINE SHORT BLOCK KIT
-
4369-87122-1 CARBURETOR REPAIR KITCARBURETOR REPAIR KIT
-
4369-02011-0 * CARBURETOR GASKET* CARBURETOR GASKET
-
4369-03222-0 * FLOAT CHAMBER O-RING* FLOAT CHAMBER O-RING
-
4369-03293-1 * GASKET* GASKET
-
4922503-6412 * SCREW* SCREW
-
4369-03231-0 * FLOAT* FLOAT
-
4346-03232-0 * FLOAT ARM PIN* FLOAT ARM PIN
-
4369-03240-0 * FLOAT VALVE* FLOAT VALVE
-
4344-03244-0 * CLIP* CLIP
-
4921521-0408 * SCREW* SCREW
-
4346-03256-0 * RUBBER CAP* RUBBER CAP
-
4369-03303-0 * DIAPHRAGM A* DIAPHRAGM A
-
4369-03306-0 * DIAPHRAGM B* DIAPHRAGM B
-
4922553-6423 * SCREW* SCREW
-
4369-03302-0 * PUMP COVER GASKET* PUMP COVER GASKET
-
4369-03307-0 * PUMP BODY GASKET* PUMP BODY GASKET
-
4369-03182-0 * CARBURETOR COVER GASKET* CARBURETOR COVER GASKET
-
4369-03183-0 * CARBURETOR COVER GASKET* CARBURETOR COVER GASKET
-
4369-03186-0 * SCREW* SCREW
-
5369-87121-5 POWER HEAD GASKET SETPOWER HEAD GASKET SET
-
5369-01005-2 * CYLINDER HEAD GASKET* CYLINDER HEAD GASKET
-
5369-01215-0 * OIL SEAL 10.1-25-7
Crankcase Head* OIL SEAL 10.1-25-7
Crankcase Head -
5369-01214-0 * CRANKCASE HEAD GASKET* CRANKCASE HEAD GASKET
-
5369-00122-0 * OIL SEAL 20-47-8
Crankshaft* OIL SEAL 20-47-8
Crankshaft -
5369-03222-0 * FLOAT CHAMBER O-RING* FLOAT CHAMBER O-RING
-
5369-03293-1 * GASKET* GASKET
-
5369-02011-0 * CARBURETOR GASKET* CARBURETOR GASKET
-
5369-61012-2 * DRIVE SHAFT HOUSING GASKET* DRIVE SHAFT HOUSING GASKET
-
6369-87322-1 WATER PUMP REPAIR KITWATER PUMP REPAIR KIT
-
6369-65018-0 * PUMP CASE GASKET* PUMP CASE GASKET
-
6369-65025-0 * WATER PUMP GUIDE PLATE* WATER PUMP GUIDE PLATE
-
6369-65029-0 * GUIDE PLATE GASKET* GUIDE PLATE GASKET
-
6369-65020-0 * PUMP CASE GASKET (LOWER)* PUMP CASE GASKET (LOWER)
-
69161E3-0645 * BOLT* BOLT
-
6940103-0600 * WASHER* WASHER
-
6369-65022-0 * KEY φ2-11* KEY φ2-11
-
6369-65011-0 * PUMP CASE LINER* PUMP CASE LINER
-
6369-65021-1 * WATER PUMP IMPELLER* WATER PUMP IMPELLER
-
7369-65231-0 WATER PUMP KIT (CHROME PLATED)WATER PUMP KIT (CHROME PLATED)
-
7369-65021-1 * WATER PUMP IMPELLER* WATER PUMP IMPELLER
-
7369-65238-0 * PUMP CASE LINER
Chrome Plated* PUMP CASE LINER
Chrome Plated -
7369-65239-0 * WATER PUMP GUIDE PLATE
Chrome Plated* WATER PUMP GUIDE PLATE
Chrome Plated -
7369-65018-0 * PUMP CASE GASKET* PUMP CASE GASKET
-
7369-65029-0 * GUIDE PLATE GASKET* GUIDE PLATE GASKET
-
8369-87321-0 LOWER UNIT GASKET SETLOWER UNIT GASKET SET
-
8332-60006-0 * GASKET 8.1-15-1* GASKET 8.1-15-1
-
8369-60111-0 * OIL SEAL 15-28-10
Propeller Shaft* OIL SEAL 15-28-10
Propeller Shaft -
8345-65015-0 * O-RING 3.2-47
Propeller Shaft Housing* O-RING 3.2-47
Propeller Shaft Housing -
8369-65018-0 * PUMP CASE GASKET* PUMP CASE GASKET
-
8369-65029-0 * GUIDE PLATE GASKET* GUIDE PLATE GASKET
-
8369-60223-0 * OIL SEAL 10-24-8
Pump Case(Lower)* OIL SEAL 10-24-8
Pump Case(Lower) -
8369-65020-0 * PUMP CASE GASKET (LOWER)* PUMP CASE GASKET (LOWER)
-
8369-66021-1 * O-RING 2.5-4.9
Cam Rod* O-RING 2.5-4.9
Cam Rod -
8332-66032-0 * O-RING 2.4-15.4
Cam Rod Bushing* O-RING 2.4-15.4
Cam Rod Bushing
