OPTIONAL PARTS (3) ACCESSORIES для Tohatsu M5B - 2018 года выпуска`
-
№АртикулНазвание
-
1369-72100-0 TOOL KITTOOL KIT
-
2312-72201-0 SAFETY ROPE φ4-1000SAFETY ROPE φ4-1000
-
3399-76101-0 LIGHTING KITLIGHTING KIT
-
43H6-06128-0 * ALTERNATOR KIT
12V60W* ALTERNATOR KIT
12V60W -
5399-06023-1 ** ALTERNATOR ASSY (60W)
12V60W** ALTERNATOR ASSY (60W)
12V60W -
6921521-6520 ** SCREW** SCREW
-
7369-06915-0 ** CLAMP 4.2-3-8** CLAMP 4.2-3-8
-
8921521-6408 ** SCREW** SCREW
-
9369-76167-0 * EXTENSION CORD (LIGHT) L=2000* EXTENSION CORD (LIGHT) L=2000
-
10345-66226-0 * GROMMET 17-3* GROMMET 17-3
-
113H6-76160-0 * RECTIFIER KIT* RECTIFIER KIT
-
12369-76060-1 ** RECTIFIER COMPLETE** RECTIFIER COMPLETE
-
13334-76211-0 *** FUSE 10A*** FUSE 10A
-
14921503-0525 ** SCREW** SCREW
-
15940103-0500 ** WASHER** WASHER
-
16941303-0500 ** SPRING WASHER** SPRING WASHER
-
17930103-0500 ** NUT** NUT
-
18353-06972-0 ** CLAMP 7-80P** CLAMP 7-80P
-
19369-76161-0 ** EXTENSION CORD** EXTENSION CORD
-
20399B05180-0 VERTICAL STARTER KITVERTICAL STARTER KIT
-
21369B05911-0 * VERTICAL STARTER GUIDE* VERTICAL STARTER GUIDE
-
22369-05913-0 * TAPPING SCREW M6-12* TAPPING SCREW M6-12
-
233B2-05912-0 * SEAL* SEAL
-
24336-60007-0 FLUSHING PLUGFLUSHING PLUG
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHIFT
- CARBURETOR
- RECOIL STARTER STARTER LOCK
- MAGNETO
- DRIVE SHAFT HOUSING SHIFT
- GEAR CASE
- BRACKET REVERSE LOCK ARM
- BOTTOM COWL TILLER HANDLE
- TOP COWL
- INTEGRAL FUEL TANK (M4C M5B M5B-D)
- SEPARATE FUEL TANK DUAL FUEL (M5B-D M5B-S)
- OPTIONAL PARTS (1) ACCESSORIES (REMOTE CONTROL)
- OPTIONAL PARTS (2) REMOTE CONTROL BOX
- • OPTIONAL PARTS (3) ACCESSORIES
- ASSEMBLY KIT PARTS
