OPTIONAL PARTS (1) для Tohatsu M25H - 2017 года выпуска`
-
№АртикулНазвание
-
13C8-72100-1 TOOL KITTOOL KIT
-
23B7-72201-0 SAFETY ROPE φ5-1600SAFETY ROPE φ5-1600
-
3336-60007-0 FLUSHING PLUGFLUSHING PLUG
-
43P0-66901-0 REVERSE LOCK SHIFT LEVER KITREVERSE LOCK SHIFT LEVER KIT
-
5345-67169-0 GROMMET 40-13-3GROMMET 40-13-3
-
6346-76160-2 RECTIFIER KITRECTIFIER KIT
-
73B7-72530-2 TACHOMETER ASSYTACHOMETER ASSY
-
83B7-72659-0 * METER BULB 12V-1.7W* METER BULB 12V-1.7W
-
93B7-72656-0 * METER DAMPER* METER DAMPER
-
103B7-72661-0 * FITTING PLATE* FITTING PLATE
-
11930103-0500 * NUT* NUT
-
12941303-0500 * SPRING WASHER* SPRING WASHER
-
13361-72539-0 TACHOMETER LEAD WIRE L=6000TACHOMETER LEAD WIRE L=6000
-
143P0-72679-0 TACHOMETER UNIT KITTACHOMETER UNIT KIT
-
15361-72542-0 SEPARATE CORD
WhiteSEPARATE CORD
White -
15361-72543-0 SEPARATE CORD
YellowSEPARATE CORD
Yellow
Все узлы модели:
- CYLINDER CRANK CASE
- PISTON CRANK SHAFT
- INTAKE MAINFOLD FUEL PUMP
- CARBURETOR
- RECOIL STARTER
- MAGNETO
- ELECTRIC PARTS
- DRIVE SHAFT HOUSING
- GEAR CASE (DRIVE SHAFT)
- GEAR CASE (PROPELLER SHAFT)
- BRACKET
- TILLER HANDLE
- BOTTOM COWL
- SHIFT
- REMOTE CONTROL PARTS
- TOP COWL
- FUEL TANK
- COMPONENT PARTS OF REMOTE CONTROL
- COMPONENT PARTS OF REMOTE CONTROL (ELECTRIC PARTS)
- • OPTIONAL PARTS (1)
- OPTIONAL PARTS (2)
- ASSEMBLY KIT PARTS
