FUEL TANK для Tohatsu M25H - 2017 года выпуска`
-
№АртикулНазвание
-
13B7-70200-5 PRIMER BULB ASSYPRIMER BULB ASSY
-
23C7-70220-1 * JOINT ASSY (INLET)* JOINT ASSY (INLET)
-
33C7-70224-1 * JOINT ASSY (OUTLET)* JOINT ASSY (OUTLET)
-
43C7-70211-1 * PRIMER BULB* PRIMER BULB
-
53C7-70217-0 * CLAMP* CLAMP
-
698AB-70-700 * HOSE
98AB-701000* HOSE
98AB-701000 -
798AB-701600 * HOSE
98AB-701000 x2* HOSE
98AB-701000 x2 -
83B7-70280-1 * FUEL CONNECTOR MARK* FUEL CONNECTOR MARK
-
93GF-70281-0 * FUEL CONNECTOR* FUEL CONNECTOR
-
103GF-70250-1 * FUEL CONNECTOR* FUEL CONNECTOR
-
11332-70201-0 * CLAMP* CLAMP
-
123C7-70177-1 FUEL TANK ASSY 25LFUEL TANK ASSY 25L
-
133C7-70050-2 * FUEL GAUGE VENT CAP ASSY (25L)* FUEL GAUGE VENT CAP ASSY (25L)
-
143C7-70155-0 * PICK-UP ELBOW ASSY (25L)* PICK-UP ELBOW ASSY (25L)
-
153E0-70270-0 * QUICK-CONNECTOR (MALE)* QUICK-CONNECTOR (MALE)
-
163C7-70199-0 * O-RING* O-RING
-
173C7-70113-0 * FILTER* FILTER
