INTAKE SILENCER CARBURETOR для Tohatsu MWX50D2 - 2015 года выпуска
-
№АртикулНазвание
-
13C8-02420-0 BOLT 5-16BOLT 5-16
-
23C8-02418-0 GASKET
Seal RubberGASKET
Seal Rubber -
33C8-02415-0 INTAKE SILENCER COVERINTAKE SILENCER COVER
-
43F3-02423-0 TAPPING SCREW 5-30TAPPING SCREW 5-30
-
53LC-03200-1 CARBURETOR ASSY
for MX50D2, MWX50D2 Upper 3LC 0CARBURETOR ASSY
for MX50D2, MWX50D2 Upper 3LC 0 -
63LC-03207-1 CARBURETOR ASSY (SECOND)
for MX50D2, MWX50D2 Center 3LC 0CARBURETOR ASSY (SECOND)
for MX50D2, MWX50D2 Center 3LC 0 -
73LC-04438-0 * MAIN JET (#138)
for MX50D2, MWX50D2 X 3* MAIN JET (#138)
for MX50D2, MWX50D2 X 3 -
83M2-03152-0 * SLOW JET (#80)
for M50D2, MW50D2 X 3 MX50D2, MWX50D2* SLOW JET (#80)
for M50D2, MW50D2 X 3 MX50D2, MWX50D2 -
93C8-03169-0 * PLUG
X 3* PLUG
X 3 -
103LD-03147-0 * FLOAT VALVE
for MX50D2, MWX50D2 X 3* FLOAT VALVE
for MX50D2, MWX50D2 X 3 -
113C8-03126-0 * FLOAT ARM PIN
X 3* FLOAT ARM PIN
X 3 -
123C8-03125-0 * FLOAT
X 3* FLOAT
X 3 -
13921722-0410 * SCREW
X 3* SCREW
X 3 -
143C8-03179-1 * STOP SCREW
Upper X 1* STOP SCREW
Upper X 1 -
153C8-03157-0 * SPRING
Upper X 2, Center X 1,Lower X 1* SPRING
Upper X 2, Center X 1,Lower X 1 -
163G2-03156-0 * ADJUST SCREW
X 3* ADJUST SCREW
X 3 -
173C8-03120-0 * FLOAT CHAMBER
Upper, Center X 2* FLOAT CHAMBER
Upper, Center X 2 -
183C8-03121-0 * FLOAT CHAMBER GASKET
O-Ring X 3* FLOAT CHAMBER GASKET
O-Ring X 3 -
19910306-0405 * BOLT
X 3* BOLT
X 3 -
203C8-03193-0 * GASKET
X 3* GASKET
X 3 -
213E3-03141-0 * MAIN NOZZLE
for M50D2, MW50D2 X 3 MX50D2, MWX50D2* MAIN NOZZLE
for M50D2, MW50D2 X 3 MX50D2, MWX50D2 -
223C8-03181-0 * CARBURETOR COVER
X 3* CARBURETOR COVER
X 3 -
233C8-03182-0 * CARBURETOR COVER GASKET
X 3* CARBURETOR COVER GASKET
X 3 -
24922503-6410 * SCREW
C/Cover, Float Chamber X 3* SCREW
C/Cover, Float Chamber X 3 -
253LC-03210-1 CARBURETOR ASSY (THIRD)
for MX50D2, MXW50D2 Lower 3LC 0CARBURETOR ASSY (THIRD)
for MX50D2, MXW50D2 Lower 3LC 0 -
263C8-04004-0 * PUMP COVER
Lower* PUMP COVER
Lower -
273E3-64333-0 * PRE-COATED SCREW
Lower* PRE-COATED SCREW
Lower -
283C8-04018-0 * PUMP COVER GASKET
Lower* PUMP COVER GASKET
Lower -
29350-04014-0 * CHECK VALVE
Lower* CHECK VALVE
Lower -
30921703-0305 * SCREW
Lower* SCREW
Lower -
31930203-0300 * NUT
Lower* NUT
Lower -
32350-04005-0 * PUMP DIAPHRAGM
Lower* PUMP DIAPHRAGM
Lower -
333C8-04028-0 * PUMP BODY GASKET
Lower* PUMP BODY GASKET
Lower -
343C8-04002-0 * PUMP BODY
Lower* PUMP BODY
Lower -
353C8-03123-0 * LOWER FLOAT CHAMBER
Lower* LOWER FLOAT CHAMBER
Lower -
363E3-02011-0 CARBURETOR GASKET
for M50D2, MW50D2 MX50D2, MWX50D2CARBURETOR GASKET
for M50D2, MW50D2 MX50D2, MWX50D2 -
37916103-0685 BOLTBOLT
-
38941303-0600 SPRING WASHERSPRING WASHER
-
39940103-0600 WASHERWASHER
-
4098AB-50-080 HOSE
98AB-501000HOSE
98AB-501000 -
41338-02215-0 CLIPφ10CLIPφ10
-
42348-63717-1 ROD 5-68ROD 5-68
-
433B7-05229-0 BALL JOINT CONNECTORBALL JOINT CONNECTOR
-
443B7-05243-0 BALL JOINT CONNECTORBALL JOINT CONNECTOR
-
45930103-0500 NUTNUT
-
463C8-67191-1 CHOKE ROD 3-90CHOKE ROD 3-90
-
473E3-02411-0 INTAKE SILENCER
for M50D2, MW50D2 MX50D2, MWX50D2INTAKE SILENCER
for M50D2, MW50D2 MX50D2, MWX50D2 -
48346-67196-1 ROD SNAP 3-BROD SNAP 3-B
-
493C8-02417-0 INTAKE SILENCER LOCK PLATEINTAKE SILENCER LOCK PLATE
-
513C8-67192-0 CHOKE RODCHOKE ROD
-
52346-67196-1 ROD SNAP 3-BROD SNAP 3-B
