OPTIONAL PARTS (ACCESSORIES) для Tohatsu M6B - 2012 года выпуска`
-
№АртикулНазвание
-
18-1312-72201-0 SAFETY ROPE ?4-1000SAFETY ROPE ?4-1000
-
18-2369-72100-0 TOOL KITTOOL KIT
-
18-3346-76160-2 RECTIFIER KIT
for MFRECTIFIER KIT
for MF -
18-43B2-06128-0 ALTERNATOR KIT
for MFALTERNATOR KIT
for MF -
18-5921521-6625 * SCREW* SCREW
-
18-6369-76167-0 EXTENSION CORD (LIGHT) L=2000
for MFEXTENSION CORD (LIGHT) L=2000
for MF -
18-73B7-72530-2 TACHOMETER ASSYTACHOMETER ASSY
-
18-83B7-72659-0 * METER BULB 12V-1.8W* METER BULB 12V-1.8W
-
18-93B7-72656-0 * METER DAMPER* METER DAMPER
-
18-103B7-72661-0 * FITTING PLATE* FITTING PLATE
-
18-11930103-0500 * NUT* NUT
-
18-12941303-0500 * SPRING WASHER* SPRING WASHER
-
18-13361-72539-0 TACHOMETER LEAD WIRE L=6000TACHOMETER LEAD WIRE L=6000
-
18-14345-67169-0 GROMMETGROMMET
-
18-15361-72543-0 SEPARATE CORD
YellowSEPARATE CORD
Yellow -
18-15361-72542-0 SEPARATE CORD
WhiteSEPARATE CORD
White -
18-163B2B05180-0 VERTICAL STARTER KITVERTICAL STARTER KIT
-
18-173B2B05911-0 * VERTICAL STARTER GUIDE* VERTICAL STARTER GUIDE
-
18-189101F4-0654 * BOLT* BOLT
-
18-19940103-0600 * WASHER* WASHER
-
18-20930103-0600 * NUT* NUT
-
18-213B2-05912-0 * SEAL* SEAL
-
18-23336-60007-0 FLUSHING PLUGFLUSHING PLUG
-
18-243B2B63037-0 LONG HANDLELONG HANDLE
