ELECTRIC PARTS (C.D. UNIT) для Tohatsu M50D2 - 2012 года выпуска`
-
№АртикулНазвание
-
13C8-06048-0 IGNITION COIL ASSY W/LABEL
for M40/50D2, MW50D2 F6T530IGNITION COIL ASSY W/LABEL
for M40/50D2, MW50D2 F6T530 -
3346-06999-0 * PLUG CAP W/RESISTANCE
for M40/50D2, MW50D2* PLUG CAP W/RESISTANCE
for M40/50D2, MW50D2 -
73C8-72181-0 * CAUTION DECAL (B)* CAUTION DECAL (B)
-
83C7-06040-0 IGNITION COIL W/R-CAP
for M40/50D2, MW50D2 F6T530IGNITION COIL W/R-CAP
for M40/50D2, MW50D2 F6T530 -
10346-06999-0 * PLUG CAP W/RESISTANCE
for M40/50D2, MW50D2* PLUG CAP W/RESISTANCE
for M40/50D2, MW50D2 -
14910103-5620 BOLTBOLT
-
15151-33159-0 GASKET 6.2-11-1GASKET 6.2-11-1
-
163C7-76142-1 GROUND CABLE L=170
#3 Ignition Coil -Cylinder BlockGROUND CABLE L=170
#3 Ignition Coil -Cylinder Block -
17336-76091-0 LEAD WIRE BANDLEAD WIRE BAND
-
183C8-06160-1 CD UNIT
F8T20572CD UNIT
F8T20572 -
193B7-60103-0 O-RING 3.1-94.4O-RING 3.1-94.4
-
203C8B06901-1 BRACKET
Black for M40/50D2, MW50D2BRACKET
Black for M40/50D2, MW50D2 -
22353-76213-0 SPARE FUSE 20A
for EF/EP TypeSPARE FUSE 20A
for EF/EP Type -
233C8-06902-0 COVERCOVER
-
243C8-72028-0 WIRING DIAGRAM DECAL
for EF/EP TypeWIRING DIAGRAM DECAL
for EF/EP Type -
25921503-5514 SCREWSCREW
-
26346-67113-0 MOUNT 8.5-14-2.5MOUNT 8.5-14-2.5
-
273B7-06920-0 RUBBER MOUNT 8.5-14-2.5RUBBER MOUNT 8.5-14-2.5
-
28346-67114-1 SPACER 6.2-9-15.7SPACER 6.2-9-15.7
-
29910103-6630 BOLTBOLT
-
30346-67115-0 WASHER 6.5-21-1WASHER 6.5-21-1
-
313N4-76142-1 GROUND CABLE L=270
Electric Bracket -Bottom CowlGROUND CABLE L=270
Electric Bracket -Bottom Cowl -
32910103-0612 BOLT
for Manual Tilt ModelBOLT
for Manual Tilt Model -
33353-06972-0 CLAMP 7-80P
for EF/EP TypeCLAMP 7-80P
for EF/EP Type -
34910403-0612 BOLT
for EF/EP TypeBOLT
for EF/EP Type
