CARBURETOR для Tohatsu M2.5A2 - 2012 года выпуска`
-
№АртикулНазвание
-
13D5-03100-5 Carburetor Ass'y
C6 for M2.5A2Carburetor Ass'y
C6 for M2.5A2 -
2309-03170-0 * Throttle Wire Ass'y* Throttle Wire Ass'y
-
3309-03178-0 * Screw* Screw
-
4309-03173-0 * Throttle Lever Holder* Throttle Lever Holder
-
5309-03101-0 * Carburetor Body Cap* Carburetor Body Cap
-
6309-03107-0 * Throttle Valve Spring* Throttle Valve Spring
-
7309-03108-0 * Spring Receiver* Spring Receiver
-
8309-03154-0 * Jet Needle Clip* Jet Needle Clip
-
93F0-03153-3 * Jet Needle #256* Jet Needle #256
-
103D5-03106-0 * Throttle Valve
for M2.5A2* Throttle Valve
for M2.5A2 -
11309-03155-2 * Needle Jet* Needle Jet
-
12309-03121-0 * Float Chamber Gasket* Float Chamber Gasket
-
13309-03125-0 * Float* Float
-
14309-03120-0 * Float Chamber* Float Chamber
-
15309-03192-0 * Drain Screw* Drain Screw
-
16309-03193-0 * Gasket* Gasket
-
17309-03151-3 * Main Jet (#86)* Main Jet (#86)
-
18309-03126-0 * Float Arm Pin* Float Arm Pin
-
19309-03127-1 * Float Hinge* Float Hinge
-
20309-03147-1 * Float Valve* Float Valve
-
21309-03148-1 * Needle Valve Seat* Needle Valve Seat
-
22309-03156-0 * Adjust Screw* Adjust Screw
-
23309-03157-0 * Spring* Spring
-
24309-03161-0 * Choke Plate* Choke Plate
-
25332-03104-0 * Choke Plate Nut* Choke Plate Nut
-
26941303-0600 * Spring Washer* Spring Washer
-
27309-03163-0 * Shutter Bolt* Shutter Bolt
-
28309-03164-0 * Shutter Lever* Shutter Lever
-
29309-03113-0 * Carburetor Body Band* Carburetor Body Band
-
30309-03114-0 * Carburetor Body Band Bolt* Carburetor Body Band Bolt
-
31921532-6410 * Screw* Screw
-
32921532-0510 * Screw* Screw
-
33309-03177-0 * Throttle Lever Washer* Throttle Lever Washer
-
34309-03175-0 * Throttle Lever Gasket* Throttle Lever Gasket
-
35309-03176-1 * Throttle Lever End* Throttle Lever End
-
36309-03174-1 * Throttle Lever Collar* Throttle Lever Collar
-
37309-03172-1 * Throttle Lever* Throttle Lever
-
38309-03116-2 * O-Ring 2.4-15.7* O-Ring 2.4-15.7
-
39309-03401-0 * Knob* Knob
-
40921603-0305 ScrewScrew
-
41314B02496-2 Carburetor Cover W/Decal
for M2.5A2Carburetor Cover W/Decal
for M2.5A2 -
42921603-0435 ScrewScrew
