DRIVE SHAFT HOUSING GEAR CASE для Tohatsu M8B - 2008 года выпуска
-
№АртикулНазвание
-
13B2Q61020-1 Drive Shaft Housing “S”
for Transom “S”Drive Shaft Housing “S”
for Transom “S” -
13B2Q61030-1 Drive Shaft Housing “L”
for Transom “L” “UL”Drive Shaft Housing “L”
for Transom “L” “UL” -
2910113-5635 BoltBolt
-
33B2-61012-0 Drive Shaft Housing GasketDrive Shaft Housing Gasket
-
43B2-01111-0 Dowel Pin, 6-16Dowel Pin, 6-16
-
53B2Q61110-2 Extension Housing “UL”
for Transom “UL”Extension Housing “UL”
for Transom “UL” -
6910113-5635 Bolt
for Transom “UL”Bolt
for Transom “UL” -
73B2-60003-1 Drive Shaft Bushing
for Transom “UL”Drive Shaft Bushing
for Transom “UL” -
8353-66024-0 Drive Shaft Bushing Stopper
for Transom “UL”Drive Shaft Bushing Stopper
for Transom “UL” -
9910103-6612 Bolt
for Transom “UL”Bolt
for Transom “UL” -
103AAQ60000-0 Gear Case (New)
(# 016853XD~)Gear Case (New)
(# 016853XD~) -
103V1S60000-0 Gear Case (Old)
# 036520XC~# 010321XDGear Case (Old)
# 036520XC~# 010321XD -
103B2S60000-0 Gear Case (Old)
~# 032557XCGear Case (Old)
~# 032557XC -
10-13V1-60211-0 * Needle Bearing, 15-21-16
or 3B2-60211-0* Needle Bearing, 15-21-16
or 3B2-60211-0 -
11910113-5635 BoltBolt
-
123AA-60206-0 Water Strainer (New)
W=17 Mark “A” # 016853XD~Water Strainer (New)
W=17 Mark “A” # 016853XD~ -
123V1-60206-0 Water Strainer (Old)
W=14 # 036520XC~ 010321XDWater Strainer (Old)
W=14 # 036520XC~ 010321XD -
13921513-0430 ScrewScrew
-
14930403-0400 Nylon Nut, 4P-0.7Nylon Nut, 4P-0.7
-
15332-60005-2 Oil PlugOil Plug
-
16332-60005-2 Water PlugWater Plug
-
17332-60006-0 Gasket, 8.1-15-1Gasket, 8.1-15-1
-
183V1-60217-0 Trim Tab
# 036520XC~Trim Tab
# 036520XC~ -
18338-60218-2 Anode
~# 032877XCAnode
~# 032877XC -
19910103-5620 Bolt
# 036520XC~Bolt
# 036520XC~ -
19910103-0616 Bolt
~# 032877XCBolt
~# 032877XC -
209601-0-6204 Ball Bearing, 6204Ball Bearing, 6204
-
213B2Q60101-0 Propeller Shaft HousingPropeller Shaft Housing
-
22910113-5620 BoltBolt
-
23345-65015-0 O-Ring, 3.2-47O-Ring, 3.2-47
-
24369-60111-0 Oil Seal, 15-28-10Oil Seal, 15-28-10
-
259601-0-6004 Ball Bearing, 6004Ball Bearing, 6004
-
26369-66043-1 Cam Rod GrommetCam Rod Grommet
-
273B2-02311-0 Exhaust PipeExhaust Pipe
-
283B2-02312-0 Exhaust Pipe GasketExhaust Pipe Gasket
-
29910113-5618 Bolt
or 910103-5618Bolt
or 910103-5618 -
30910103-5612 BoltBolt
