TRANSMISSION WATER PUMP для Tohatsu M6B - 2007 года выпуска

  • №
    Артикул
    Название
  • 1
    3V1-64306-1 Drive Shaft “S”
    for Transom “S” or 3B2643011
    Drive Shaft “S”
    for Transom “S” or 3B2643011
  • 1
    3V1-64307-1 Drive Shaft “L”
    for Transom “L” or 3B2643021
    Drive Shaft “L”
    for Transom “L” or 3B2643021
  • 1
    3V1-64309-1 Drive Shaft “UL”
    for Transom “UL” or 3B2643031
    Drive Shaft “UL”
    for Transom “UL” or 3B2643031
  • 1-1
    9601-0-6301 * Ball Bearing, 6301
    * Ball Bearing, 6301
  • 2
    3B2-64010-0 Bevel Gear “A”
    Bevel Gear “A”
  • 3
    3B2-64020-0 Bevel Gear “B”
    Bevel Gear “B”
  • 4
    3B2-64030-0 Bevel Gear “C”
    Bevel Gear “C”
  • 5
    369-64032-0 Washer, 15.2-19-1.9
    Washer, 15.2-19-1.9
  • 6
    369-64014-0 Shim, 21-28-0.1
    Shim, 21-28-0.1
  • 6
    369-64015-0 Shim, 21-28-0.15
    Shim, 21-28-0.15
  • 7
    3V1-64211-0 Propeller Shaft
    or 3B2642110
    Propeller Shaft
    or 3B2642110
  • 8
    3B2W64513-1 Propeller (6.5), 3X8.5X 6.5
    Propeller (6.5), 3X8.5X 6.5
  • 8
    3B2W64514-1 Propeller (7), 3X8.9X 7.0
    8B/6B STD. “L”, “UL”
    Propeller (7), 3X8.9X 7.0
    8B/6B STD. “L”, “UL”
  • 8
    3B2W64515-1 Propeller (7.5), 3X8.5X 7.5
    9.8B STD. “L”, “UL”
    Propeller (7.5), 3X8.5X 7.5
    9.8B STD. “L”, “UL”
  • 8
    3B2W64517-1 Propeller (8.5), 3X8.9X8.3
    9.8B/8B/6B STD. “S”
    Propeller (8.5), 3X8.9X8.3
    9.8B/8B/6B STD. “S”
  • 8
    3B2W64519-1 Propeller (9.5), 3x8.9x10.0
    Old Part No. 3B2645180
    Propeller (9.5), 3x8.9x10.0
    Old Part No. 3B2645180
  • 9
    369-64121-0 Propeller Nut
    Propeller Nut
  • 10
    951503-0318 Split Pin, 3-18
    Split Pin, 3-18
  • 11
    369-64124-0 Washer, 10.5-28-2
    Washer, 10.5-28-2
  • 12
    3B2-64230-1 Propeller Thrust Holder
    # 044907XC~
    Propeller Thrust Holder
    # 044907XC~
  • 13
    3B2-64215-0 Clutch
    Clutch
  • 14
    301-64217-0 Spring Pin, 3.5-28
    Spring Pin, 3.5-28
  • 15
    3V1-64221-0 Clutch Spring
    # 032113XC~ or 3B2642210
    Clutch Spring
    # 032113XC~ or 3B2642210
  • 16
    369-64223-0 Clutch Push Rod
    Clutch Push Rod
  • 17
    3B2-64222-0 Clutch Spring Retainer
    Clutch Spring Retainer
  • 18
    3B2-65021-1 Water Pump Impeller
    Water Pump Impeller
  • 19
    3B2-65022-0 Water Pump Impeller Key
    Water Pump Impeller Key
  • 20
    3B2-65016-0 Pump Case (Upper)
    Pump Case (Upper)
  • 21
    3B2-65011-0 Pump Case Liner
    Pump Case Liner
  • 22
    3B2-65025-0 Water Pump Guide Plate
    Water Pump Guide Plate
  • 23
    3B2-65018-0 Pump Case Gasket (Upper)
    Pump Case Gasket (Upper)
  • 24
    3B2-65029-0 Pump Guide Plate Gasket
    Pump Guide Plate Gasket
  • 25
    916113-0650 Bolt
    Bolt
  • 26
    940113-0600 Washer
    Washer
  • 27
    3V1-65017-0 Pump Case (Lower)
    or 3B2650170
    Pump Case (Lower)
    or 3B2650170
  • 28
    3B2-65020-0 Pump Case Gasket (Lower)
    Pump Case Gasket (Lower)
  • 29
    309-60111-0 Oil Seal, 12-24-8
    Oil Seal, 12-24-8
  • 30
    3B2-64023-0 Gap Liner, 28-36.8
    t=0.1, 0.15, 0.3
    Gap Liner, 28-36.8
    t=0.1, 0.15, 0.3
  • 31
    3B2-65100-0 Water Pipe “S”
    for Transom “S”
    Water Pipe “S”
    for Transom “S”
  • 31
    3B2-65110-0 Water Pipe “L”
    for Transom “L”
    Water Pipe “L”
    for Transom “L”
  • 31
    3B2-65120-0 Water Pipe “UL”
    for Transom “UL”
    Water Pipe “UL”
    for Transom “UL”
  • 32
    3B2-65195-0 Water Pipe Seal (Upper)
    Water Pipe Seal (Upper)
  • 33
    331-65014-0 Water Pipe Seal (Lower)
    Water Pipe Seal (Lower)
  • 34
    369-66033-0 Cam Rod Bushing Stopper
    Cam Rod Bushing Stopper
  • 35
    910103-5625 Bolt
    or 9101135625
    Bolt
    or 9101135625
