Top cowl (upper motor cover) для Tohatsu MD90B - 2006 года выпуска`
-
№АртикулНазвание
-
13T9Q67510-2 Motor cover upper md70/90 (aqua marine blue)
Motor Cover (Upper), UniqueMotor cover upper md70/90 (aqua marine blue)
Motor Cover (Upper), Unique -
1-13C7-67501-0 Seal rubber upper motor coverSeal rubber upper motor cover
-
1-10353-67142-1 Cover HookCover Hook
-
1-11910103-6616 BoltBolt
-
1-123C8-66308-0 New partNew part
-
1-133T9Q67521-1 Tilt handleTilt handle
-
1-163E3Q67210-0 Filler lid (aqua marine blue)Filler lid (aqua marine blue)
-
3E3Q67210-1 Filler lid (aqua marine blue)Filler lid (aqua marine blue)
-
1-173B7-67211-0 Hinge, Filler LidHinge, Filler Lid
-
1-183C8-67212-0 Spring filler lidSpring filler lid
-
1-19910103-0614 BoltBolt
-
1-2353-67517-1 Locating bracketLocating bracket
-
1-20941303-0600 New partNew part
-
1-223T9-67213-0 Seal rubber,filler lidSeal rubber,filler lid
-
1-233Y9Q87802-0 Decal set md90b (aqua marine blue)
, UniqueDecal set md90b (aqua marine blue)
, Unique -
1-3921703-5520 Stud BoltStud Bolt
-
1-4941303-0500 Spring WasherSpring Washer
-
1-5930111-0500 NutNut
-
1-63T9Q67141-0 Hook leverHook lever
-
1-7338-62435-0 O-RingO-Ring
-
1-8353-67147-1 Seal ringSeal ring
-
1-9353-67105-0 BushingBushing
-
23C7-72180-3 Caution labelCaution label
-
3C7-72180-0 Caution labelCaution label
