Assembly kit для Tohatsu MD90B - 2006 года выпуска`
-
№АртикулНазвание
-
13Y9B87110-2 Short block (70-90b/tldi)
70B # 70242-, 90B # 00766-Short block (70-90b/tldi)
70B # 70242-, 90B # 00766- -
3Y9B87090-A Short block (70-90b/tldi)Short block (70-90b/tldi)
-
23B7-87123-1 Кольца поршневыеКольца поршневые
-
23B7-00011-0 1-е поршневое кольцо1-е поршневое кольцо
-
23B7-00012-0 2-е поршневое кольцо2-е поршневое кольцо
-
2-13B7-00015-0 2-е поршневое кольцо2-е поршневое кольцо
-
2-13B7-87124-1 Кольца поршневыеКольца поршневые
-
2-13B7-00014-0 1-е поршневое кольцо1-е поршневое кольцо
-
3171-00053-0 O-Ring
, Crank Case Lower HeadO-Ring
, Crank Case Lower Head -
33B7-02235-0 O-Ring A
, Fuel Filter, Oil FilterO-Ring A
, Fuel Filter, Oil Filter -
33C7-01215-0 Oil Seal, 19.6-35-10
, Drive ShaftOil Seal, 19.6-35-10
, Drive Shaft -
33T9-87121-0 Power Head Gasket SetPower Head Gasket Set
-
33B7-02236-0 O???? b
, Fuel Filter, Oil FilterO???? b
, Fuel Filter, Oil Filter -
33T9-00121-0 Oil Seal,35-58-9
, Crankshaft LowerOil Seal,35-58-9
, Crankshaft Lower -
33T9-01005-0 Gasket,Cylinder HeadGasket,Cylinder Head
-
33B7-09002-0 O-Ring
, * Don't use for 70A2/90A2 and 70B/90B.O-Ring
, * Don't use for 70A2/90A2 and 70B/90B. -
33T9-02104-0 Gasket,Inlet ManifoldGasket,Inlet Manifold
-
33T9-01024-0 Gasket,Cylinder Head CoverGasket,Cylinder Head Cover
-
33C8-71016-0 Gasket 36-52-2Gasket 36-52-2
-
33T9-02242-0 Gasket,Air BoxGasket,Air Box
-
33T9-01032-0 Gasket,thermostat capGasket,thermostat cap
-
33C8-01303-1 Base gasketBase gasket
-
3C8-01303-4 Base gasketBase gasket
-
33T9-02245-0 Gasket,air box coverGasket,air box cover
-
33B7-02305-0 Gasket, exhaust coverGasket, exhaust cover
-
3353-00108-0 O-Ring
, Crankshaft UpperO-Ring
, Crankshaft Upper -
3346-04901-1 GasketGasket
-
346-04901-2 GasketGasket
-
43Y9Q87302-2 Lower unit assy l md90b (amb)
NewLower unit assy l md90b (amb)
New -
3Y9Q87302-7 Lower unit assy l md90b (amb)Lower unit assy l md90b (amb)
-
43Y9Q87304-2 Lower unit assy ul md90b (amb)
NewLower unit assy ul md90b (amb)
New -
3Y9Q87304-0 Lower unit assy ul md90b (amb)Lower unit assy ul md90b (amb)
-
53B7Q87323-1 Propeller shaft housing assy (amb)Propeller shaft housing assy (amb)
-
63C7-65029-0 Gasket Pump Guide PlateGasket Pump Guide Plate
-
63C7-87322-1 ウォ-タ-ポンプリペアキットウォ-タ-ポンプリペアキット
-
63C7-65021-1 Impeller water pumpImpeller water pump
-
63B7-65022-0 Key, water pump impellerKey, water pump impeller
-
63C7-65011-0 Liner Water Pump CaseLiner Water Pump Case
-
63C7-65018-0 Seal Water Pump CaseSeal Water Pump Case
-
63C7-65025-0 Guide Plate Water PumpGuide Plate Water Pump
-
73C7-65231-0 Chrome Plated Water Pump KitChrome Plated Water Pump Kit
-
73C7-65238-0 Liner chrome plated water pump caseLiner chrome plated water pump case
-
73C7-65239-0 Guide plate chrome plated water pumpGuide plate chrome plated water pump
-
83B7-65015-0 O-Ring
, Pump Case LowerO-Ring
, Pump Case Lower -
83C8-02312-0 Gasket exhaust pipeGasket exhaust pipe
-
8345-66021-0 O-Ring
, Cam RodO-Ring
, Cam Rod -
83B7-61181-0 New partNew part
-
83B7-66023-0 O-Ring
, Cam Rod BushingO-Ring
, Cam Rod Bushing -
8332-60006-0 Gasket (8.1x15.1)Gasket (8.1x15.1)
-
83B7-60103-0 O-Ring
, Propeller ShaftO-Ring
, Propeller Shaft -
83B7-60016-0 O-RingO-Ring
-
83B7-60111-0 Oil seal, 30-50-12
, Propeller ShaftOil seal, 30-50-12
, Propeller Shaft -
83C7-60223-1 Oil seal, 22-42-7
, Drive ShaftOil seal, 22-42-7
, Drive Shaft -
83T9-87321-0 Lower Unit Gasket SetLower Unit Gasket Set
-
83B7-60219-0 Packing, Trim TabPacking, Trim Tab
-
8346-64084-0 Shim, 35-41.9-0.5
, Drive Shaft Oil SealShim, 35-41.9-0.5
, Drive Shaft Oil Seal -
83B7-61012-0 New partNew part
-
9951403-3516 New partNew part
-
93B7Q61110-0 Extension housing ul (amb)Extension housing ul (amb)
-
9951403-3510 New partNew part
-
93B7-60001-2 Bolt, 10-40Bolt, 10-40
-
93C7-65120-0 Water Pipe ULWater Pipe UL
-
93B7-61112-0 Stud BoltStud Bolt
-
93B7-61114-0 NutNut
-
93C7-64303-0 Drive Shaft ULDrive Shaft UL
-
93B7-66014-1 Cam Rod ULCam Rod UL
-
93C7Q87314-0 Extension housing kit ul (amb)
70B # 70376-, 90B # 00970-Extension housing kit ul (amb)
70B # 70376-, 90B # 00970- -
3C7Q87314-2 Extension housing kit ul (amb)Extension housing kit ul (amb)
-
103T5Q84540-1 Binnacle mount control box kit dual 40/50/70/90 tldi (amb)
for Twin N.A.F.N.Binnacle mount control box kit dual 40/50/70/90 tldi (amb)
for Twin N.A.F.N.
