SEPARATE FUEL TANK (PLASTIC) для Tohatsu M5BS - 2005 года выпуска`
-
№АртикулНазвание
-
13B2-70167-0 Fuel Tank (1 2L, Plastic)
UNIQUEFuel Tank (1 2L, Plastic)
UNIQUE -
1-13B2-70050-0 * Fuel Gauge Vented Cap* Fuel Gauge Vented Cap
-
1-23C7-70021-0 * Cao Gasket* Cao Gasket
-
1-33E0-70270-0 * Male Quick Connector* Male Quick Connector
-
1-43B2-70155-0 * Elbow Tubing and Clamp Ass'y* Elbow Tubing and Clamp Ass'y
-
1-53C7-70199-0 * 0-Ring* 0-Ring
-
1-63C7-70113-0 * Filter* Filter
-
23B7-70200-3 Primer Bul b Ass'yPrimer Bul b Ass'y
-
2-198AB-7-1600 * Fuel Pipe* Fuel Pipe
-
2-23B2-70281-0 * Fuel Connector (Tank side, Female)* Fuel Connector (Tank side, Female)
-
2-398AB-7-0700 * Fuel Pipe* Fuel Pipe
-
2-4332-70201-0 * Clarno* Clarno
-
2-53C7-70211-0 * Primer Bulb* Primer Bulb
-
2-63C7-70217-0 * Clarno* Clarno
-
2-73C7-70220-1 * Joint A" Ass'y I N"* Joint A" Ass'y I N"
-
2-83C7-70224-1 * Joint A" Ass'y OUT"* Joint A" Ass'y OUT"
-
2-93B2-70250-1 * Fuel Connector (Engine side, Female)* Fuel Connector (Engine side, Female)
-
33B2-70260-1 Fuel Connector (Engine, Male)Fuel Connector (Engine, Male)
-
4369-70263-0 Bushing, Fuel ConnectorBushing, Fuel Connector
-
5941303-1000 Spring WasherSpring Washer
-
698AB-5-0150 Fuel PioeFuel Pioe
-
7369-02230-0 Fuel FilterFuel Filter
-
8338-02215-0 Clip, Fuel PioeClip, Fuel Pioe
-
998AB-5-0200 Fuel PipeFuel Pipe
-
10309-06972-0 Clarno, 6.5-47.5PClarno, 6.5-47.5P
-
11921503-0414 ScrewScrew
-
12930103-0400 NutNut
