PISTON CRANK SHAFT для Tohatsu M5B - 2005 года выпуска`
-
№АртикулНазвание
-
1369-00030-0 Crank ShaftCrank Shaft
-
1-1369-00031-0 * Crank Shaft A* Crank Shaft A
-
1-2369-00034-0 * Crank Shaft D* Crank Shaft D
-
1-3369-00061-0 * Crank Pin* Crank Pin
-
1-4369-00040-0 * Connecting Rod* Connecting Rod
-
1-5369-00043-0 * Needle Bearing, 20-26-12* Needle Bearing, 20-26-12
-
29603-3-6204 Ball Bearine:, 6204Ball Bearine:, 6204
-
3369-00115-0 Thrust Plate, Crank shaftThrust Plate, Crank shaft
-
4369-00122-0 Oil Seal, 20-47-8Oil Seal, 20-47-8
-
5350-00042-0 Needle Bearing, 14-18-20Needle Bearing, 14-18-20
-
6338-00131-0 Key, MagnetoKey, Magneto
-
7369-00001-0 Piston (Std)Piston (Std)
-
7369-00004-0 Piston (0.5mm O/S)
OptionPiston (0.5mm O/S)
Option -
8351-00011-0 Piston Rine: (Std)Piston Rine: (Std)
-
8351-00014-0 Piston Ring (0.5mm O/S)
OptionPiston Ring (0.5mm O/S)
Option -
9369-00021-0 Piston PinPiston Pin
-
10350-00024-1 Clip. Piston PinClip. Piston Pin
