GEAR CASE(PROPELLER SHAFT) для Tohatsu M3.5B2 - 2004 года выпуска`

№

Артикул

Название
1

9601-0-6004 Ball bearing, 6004

Ball bearing, 6004

2 440 ₽
2

369-64010-2 Bevel Gear A"

Bevel Gear A"

7 890 ₽
3

369-64014-0 Shim, 21-28-0.1

Shim, 21-28-0.1

660 ₽
3

369-64015-0 Shim, 21-28-0.15

Shim, 21-28-0.15

660 ₽
4

3F0-64211-0 Propeller Shaft

Propeller Shaft

12 980 ₽
5

3F0-64215-0 Clutch

Clutch

1 600 ₽
6

3F0-64221-0 Jf Spring, Clutch

Jf Spring, Clutch

510 ₽
7

3F0-64223-0 Push Rod, Clutch

Push Rod, Clutch

1 100 ₽
8

3FOS60101-1 Housing, Prooeller Shaft

Housing, Prooeller Shaft

0 ₽
9

309-60111-0 Oil Seal, 12-24-8

Oil Seal, 12-24-8

1 010 ₽
10

345-65015-0 0-Ring, 3.2-47

0-Ring, 3.2-47

360 ₽
11

9601-0-6001 Ball Beari ng:, 6001

Ball Beari ng:, 6001

2 200 ₽
12

910113-5620 Bolt

Bolt

120 ₽
13

3F0-64101-0 Propeller 7 (Plastic) ( 3 x 7.4 x 7.0)
for Transom S & L: STD

Propeller 7 (Plastic) ( 3 x 7.4 x 7.0)
for Transom S & L: STD

5 940 ₽
13

3F0-64102-0 Propeller 6 (Alum inum) ( 3 x 7.4 x 5.7)
Ootion

Propeller 6 (Alum inum) ( 3 x 7.4 x 5.7)
Ootion

14 300 ₽
13

309-64106-0 Propeller 6 (Plastic) (3 x 7.4 x 5.7)
Option

Propeller 6 (Plastic) (3 x 7.4 x 5.7)
Option

5 940 ₽
14

309-64122-2 Shear Pin A", 4-26 (Plastic Prop.)

Shear Pin A", 4-26 (Plastic Prop.)

140 ₽
14

309-64126-0 Shear Pin B'', 4-24 (Aluminum Prop.)
Ootion

Shear Pin B'', 4-24 (Aluminum Prop.)
Ootion

140 ₽
15

951503-0435 Split Pin, 4-35

Split Pin, 4-35

270 ₽
