GASKET SET для Suzuki SV1000S K6 - 2006 года выпуска

  • №
    Артикул
    Название
  • 1
    11401-06830 GASKET SET (OPT) (INCL. 2-20)
    GASKET SET (OPT) (INCL. 2-20)
  • 2
    11141-02F01 GASKET, CYLINDER HEAD
    GASKET, CYLINDER HEAD
  • 3
    11173-02F00 GASKET, CYLINDER HEAD COVER NO.1
    GASKET, CYLINDER HEAD COVER NO.1
  • 4
    11178-17E00 GASKET, CYLINDER HEAD COVER NO.2
    GASKET, CYLINDER HEAD COVER NO.2
  • 5
    11182-35F00 GASKET, 2ND AIR PASSAGE
    GASKET, 2ND AIR PASSAGE
  • 6
    11241-02F01 GASKET, CYLINDER FRONT
    GASKET, CYLINDER FRONT
  • 7
    11242-02F01 GASKET, CYLINDER REAR
    GASKET, CYLINDER REAR
  • 8
    11482-06G10 GASKET, CLUTCH COVER
    GASKET, CLUTCH COVER
  • 9
    11483-02F10 GASKET, MAGNETO COVER
    GASKET, MAGNETO COVER
  • 10
    11485-02F10 GASKET, GEAR SHIFT COVER
    GASKET, GEAR SHIFT COVER
  • 11
    12837-19B10 GASKET, TENSIONER ADJUSTER
    GASKET, TENSIONER ADJUSTER
  • 12
    12837-24A10 GASKET, TENSIONER ADJUSTER
    GASKET, TENSIONER ADJUSTER
  • 13
    14181-31D00 GASKET, EXHAUST PIPE
    GASKET, EXHAUST PIPE
  • 14
    14771-42F10 CONNECTOR, EXHAUST
    CONNECTOR, EXHAUST
  • 15
    15201-35F00 O RING, FUEL PUMP
    O RING, FUEL PUMP
  • 16
    17689-50F00 O RING
    O RING
  • 17
    09168-14002 GASKET (13.8X18.8X0.4)
    GASKET (13.8X18.8X0.4)
  • 18
    09168-14015 GASKET (14X20X1.5)
    GASKET (14X20X1.5)
  • 19
    09280-33004 O RING (D:3.1,ID:32.7)
    O RING (D:3.1,ID:32.7)
  • 20
    09280-55005 O RING (D:2.4,ID:55.6)
    O RING (D:2.4,ID:55.6)
