MAIN GEARCASE (BUILT AFTER 7/1/2018) для Polaris RANGER 570 EPS SOLAR RED (R18RME57N4) - 2018 года выпуска`
-
№АртикулНазвание
-
11334015 ASM-GEARCASE, MAIN, EBS, BRAKE, HD (INCL. ALL) (FROM 7/1/2018)ASM-GEARCASE, MAIN, EBS, BRAKE, HD (INCL. ALL) (FROM 7/1/2018)
-
23234755 PLUG, M18 X 1.5PLUG, M18 X 1.5
-
33234249 PLUG, M18 X 1.5, MAGNETICPLUG, M18 X 1.5, MAGNETIC
-
43234309 SCREW, TORX PAN HD M6 X 1 X 16SCREW, TORX PAN HD M6 X 1 X 16
-
53234898 SCREW, HEX FLANGE HEAD, M8 X 1.25 X 30SCREW, HEX FLANGE HEAD, M8 X 1.25 X 30
-
63235206 SCREW, HEX FLANGE HEAD, M6 X 1 X 20SCREW, HEX FLANGE HEAD, M6 X 1 X 20
-
73235096 SCREW, CAP HH M8 X 1.25 X 25SCREW, CAP HH M8 X 1.25 X 25
-
83235207 SCREW, HEX FLANGE M8 X 50SCREW, HEX FLANGE M8 X 50
-
93235208 SCREW, SOCKET HEAD, CAP, M6 X 1.0 X 40SCREW, SOCKET HEAD, CAP, M6 X 1.0 X 40
-
103235332 SCREW, SOCKET HEAD, CAP, M6 X 1.0 X 18SCREW, SOCKET HEAD, CAP, M6 X 1.0 X 18
-
113235210 NUT, LOCK HEX FLANGE, NYLON M8 X 1.25NUT, LOCK HEX FLANGE, NYLON M8 X 1.25
-
123234091 WASHER, CUPWASHER, CUP
-
133234952 WASHER, FENDER, 5/16 X 1.25 X .0655WASHER, FENDER, 5/16 X 1.25 X .0655
-
143235211 WASHER, 32.3 X 42 X 1.5WASHER, 32.3 X 42 X 1.5
-
153235212 WASHER, 35.6 X 57 X 1.5WASHER, 35.6 X 57 X 1.5
-
163235213 WASHER, 17.3 X 25 X 1.5WASHER, 17.3 X 25 X 1.5
-
173234330 PIN, DOWEL, 6 X 20PIN, DOWEL, 6 X 20
-
187043746 PIN, SPRING, SLOTTED 6 X 12PIN, SPRING, SLOTTED 6 X 12
-
193233106 RING, RETAINING BASIC, EXTERNAL .984RING, RETAINING BASIC, EXTERNAL .984
-
203233834 RING, SNAPRING, SNAP
-
213233364 RING, RETAINING, SHAFT, DIA. 1.375RING, RETAINING, SHAFT, DIA. 1.375
-
223234318 RING, RETAINING, EXTERNAL SHR-66RING, RETAINING, EXTERNAL SHR-66
-
233234269 RING, RETAINING BASIC, INTERNAL 2.047RING, RETAINING BASIC, INTERNAL 2.047
-
243234090 RING, RETAINING BASIC, EXTERNAL .428RING, RETAINING BASIC, EXTERNAL .428
-
253234205 RING, RETAININGRING, RETAINING
-
263235214 RING, RETAINING BASIC, EXTERNAL MSR-32RING, RETAINING BASIC, EXTERNAL MSR-32
-
273235216 RING, RETAINING, VSH-237RING, RETAINING, VSH-237
-
283235429 INPUT, SHAFT BOSS L/W UTILITYINPUT, SHAFT BOSS L/W UTILITY
-
293233378 WASHER, THRUST, 1.187 X 1.500 X .0600WASHER, THRUST, 1.187 X 1.500 X .0600
-
303234642 WASHER, THRUST, .446 X .88 X .025WASHER, THRUST, .446 X .88 X .025
-
313234272 SHIM, 1.180 OD X .995 IDSHIM, 1.180 OD X .995 ID
-
323234273 SHIM, 2.040 OD X 1.63 IDSHIM, 2.040 OD X 1.63 ID
-
333233014 BEARING, NEEDLE, CAGE ASSYBEARING, NEEDLE, CAGE ASSY
-
343233019 BEARING, BALL, 6205 C3 25X52X15BEARING, BALL, 6205 C3 25X52X15
-
353233020 BEARING, BALL, 6305 C3, 25 X 62 X 17BEARING, BALL, 6305 C3, 25 X 62 X 17
-
363233268 BEARING, BALL, 6010 C3 50X80X16BEARING, BALL, 6010 C3 50X80X16
-
373234065 BEARING, BALL, 6207 C3 35X72X17BEARING, BALL, 6207 C3 35X72X17
-
383233384 BEARING, NEEDLE, CAGE ASSYBEARING, NEEDLE, CAGE ASSY
-
393235218 BEARING, BALL, 6012 C3 60 X 95 X 18BEARING, BALL, 6012 C3 60 X 95 X 18
-
403234239 BEARING, PLAIN 10 X 12 X 25BEARING, PLAIN 10 X 12 X 25
-
413234241 BEARING, PLAIN 40 X 44 X 15BEARING, PLAIN 40 X 44 X 15
-
423234652 BEARING, BALL 6303, 17 X 47 X 14BEARING, BALL 6303, 17 X 47 X 14
-
433233830 SPRING, COMPRESSION .360 X 1.125SPRING, COMPRESSION .360 X 1.125
-
443234078 SPRING, COMPRESSION, .92 O.D. X 2.000SPRING, COMPRESSION, .92 O.D. X 2.000
-
453234089 SPRING, COMPRESSION, .46 I.D. X .73SPRING, COMPRESSION, .46 I.D. X .73
-
463234276 SPRING, TORSION, RETURNSPRING, TORSION, RETURN
-
473234277 SPRING, COMPRESSION, .54 X .44 X .050 WIRESPRING, COMPRESSION, .54 X .44 X .050 WIRE
-
483235327 SPRING, WASHERSPRING, WASHER
-
493234278 TUBE, SNORKEL MACHTUBE, SNORKEL MACH
-
503234188 COVER, SECTOR GEARS, MACHCOVER, SECTOR GEARS, MACH
-
513235463 DRUM, SHIFT MACHDRUM, SHIFT MACH
-
523233839 GEAR, SECTOR 16TGEAR, SECTOR 16T
-
533233832 GEAR, SECTOR, 31TGEAR, SECTOR, 31T
-
543235603 STAR, DETENTSTAR, DETENT
-
553235455 FORK, PIVOT SHIFT REAR DIFFFORK, PIVOT SHIFT REAR DIFF
-
563235456 PLATE, PARK 12-FACEPLATE, PARK 12-FACE
-
573235223 SHAFT, IDLER 29TSHAFT, IDLER 29T
-
583235451 SHAFT, REVERSE 25TSHAFT, REVERSE 25T
-
593235372 DISC, BRAKEDISC, BRAKE
-
603235394 SHAFT, FRONT OUTPUTSHAFT, FRONT OUTPUT
-
613235474 BELLCRANK, TITANBELLCRANK, TITAN
-
623234073 COLLAR, SHIFTCOLLAR, SHIFT
-
633234230 TUBE, VENT, 90 -1/4 IN HOSETUBE, VENT, 90 -1/4 IN HOSE
-
643234928 DOG, ENGAGEMENTDOG, ENGAGEMENT
-
653235234 GEAR, 53TGEAR, 53T
-
663233852 GEAR, LOW 67TGEAR, LOW 67T
-
673235233 DOG, ENGAGEMENT 6-FACEDOG, ENGAGEMENT 6-FACE
-
683235231 SPROCKET, 48T 6-FACESPROCKET, 48T 6-FACE
-
693235236 GEAR, 46T STAGE 3GEAR, 46T STAGE 3
-
703235237 GEAR, 13T SNORKELGEAR, 13T SNORKEL
-
713235238 SHAFT, SHIFT 3235231SHAFT, SHIFT 3235231
-
723235381 GEAR, 48T STAGE 2GEAR, 48T STAGE 2
-
733235457 SHIFT DOG, PARKSHIFT DOG, PARK
-
743235542 RAIL, SHIFT SHAFTRAIL, SHIFT SHAFT
-
753235510 WELDMENT, REAR MOUNT BRACKETWELDMENT, REAR MOUNT BRACKET
-
763234469 SUBASSEMBLY, PLANET GEAR (INCL. BUSHING)SUBASSEMBLY, PLANET GEAR (INCL. BUSHING)
-
773235373 SUBASSEMBLY, AVALANCHE DIFFERENTIALSUBASSEMBLY, AVALANCHE DIFFERENTIAL
-
793235374 SUBASSEMBLY, 39T SIDE GEAR (INCL. PLUG)SUBASSEMBLY, 39T SIDE GEAR (INCL. PLUG)
-
803235375 SUBASSY, 39T SIDE GEAR (INCL. PLUG, BUSHING)SUBASSY, 39T SIDE GEAR (INCL. PLUG, BUSHING)
-
813235378 SUBASSY, GEAR 53T (INCL. PINS, BUSHING, BEARING)SUBASSY, GEAR 53T (INCL. PINS, BUSHING, BEARING)
-
823235371 SUBASSEMBLY, PINIONSUBASSEMBLY, PINION
-
833235831 SUBASSEMBLY LEFT HAND CASE (INCL. HARDWARE)SUBASSEMBLY LEFT HAND CASE (INCL. HARDWARE)
-
843235454 SUBASSY, SHIFT FORKSUBASSY, SHIFT FORK
-
853235452 SUBASSEMBLY, PAWL, DETENT, ROLLERSUBASSEMBLY, PAWL, DETENT, ROLLER
-
863235832 SUBASSEMBLY RIGHT HAND COVER (INCL. HARDWARE)SUBASSEMBLY RIGHT HAND COVER (INCL. HARDWARE)
-
873234934 RETAINER, FORKRETAINER, FORK
-
883235241 COVER, BEARING (CENTER DRIVE)COVER, BEARING (CENTER DRIVE)
-
893235350 BRACKET, WIRE HARNESSBRACKET, WIRE HARNESS
-
905257251 BRACKET, WIRE HARNESSBRACKET, WIRE HARNESS
-
913235511 BRACKET REAR MOUNTBRACKET REAR MOUNT
-
923234249 PLUG, EXPANSION 1-1/4PLUG, EXPANSION 1-1/4
-
933235052 SEAL, TRIPLE LIP, VITON, 40 X 70 X 7SEAL, TRIPLE LIP, VITON, 40 X 70 X 7
-
943234737 CHAIN, SILENT, TYPE 101, .25P X .40W X 58LCHAIN, SILENT, TYPE 101, .25P X .40W X 58L
-
957661999 SWITCH, ROTARY , 2 PIN RESISTIVESWITCH, ROTARY , 2 PIN RESISTIVE
-
963235478 SOLENOIDSOLENOID
-
974013908 SENSOR, SPEEDSENSOR, SPEED
-
983234113 SEAL, TRIPLE LIP, 25 X 80 X 10SEAL, TRIPLE LIP, 25 X 80 X 10
-
993234892 SEAL, TRIPLE LIP, .984 X 1.850 X 0.315 VITONSEAL, TRIPLE LIP, .984 X 1.850 X 0.315 VITON
-
1003234851 SEAL, DUAL LIP, 25 X 47 VITONSEAL, DUAL LIP, 25 X 47 VITON
-
1013234302 O-RING, -113O-RING, -113
-
1023233836 O-RING, -012 VITONO-RING, -012 VITON
-
1033233828 O-RING, -014 VITONO-RING, -014 VITON
