SWING ARM для Polaris RANGER RZR 170 - RED [R11VA17AA] - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    0454508 CLAMP, TUBE, AXLE HUB (RIGHT)
    CLAMP, TUBE, AXLE HUB (RIGHT)
  • 2
    0453557 ADJUSTER, CHAIN
    ADJUSTER, CHAIN
  • 3
    0453818 NUT
    NUT
  • 4
    0454507 SHIELD, DISC, BRAKE
    SHIELD, DISC, BRAKE
  • 5
    0454506 BRACKET, CHAIN GUARD (RIGHT)
    BRACKET, CHAIN GUARD (RIGHT)
  • 6
    0452030 BOLT-HEX, 14, WASHER, NYLOCK
    BOLT-HEX, 14, WASHER, NYLOCK
  • 7
    0452198 WASHER, FLAT
    WASHER, FLAT
  • 8
    0454264 COVER, SPROCKET, REAR
    COVER, SPROCKET, REAR
  • 9
    0454275 GUARD, SPROCKET, REAR
    GUARD, SPROCKET, REAR
  • 10
    0454505 BRACKET, CHAIN GUARD (LEFT)
    BRACKET, CHAIN GUARD (LEFT)
  • 11
    0454504 CLAMP, TUBE, AXLE HUB (LEFT)
    CLAMP, TUBE, AXLE HUB (LEFT)
  • 12
    0454448 BOLT
    BOLT
  • 13
    0453669 BOLT
    BOLT
  • 14
    0452031 BOLT-HEX, 16, WASHER, NYLOCK
    BOLT-HEX, 16, WASHER, NYLOCK
  • 15
    0454509 BOLT
    BOLT
  • 16
    0454510 BUSHING
    BUSHING
  • 17
    0453706 NUT, FLANGE
    NUT, FLANGE
  • 18
    0454649-067 ARM, SWING (BLACK)
    ARM, SWING (BLACK)
  • 19
    0452954 ASM., CHAIN TENSIONER
    ASM., CHAIN TENSIONER
  • 20
    0451689 BOLT, FLANGE
    BOLT, FLANGE
  • 21
    0450298 BOLT
    BOLT
  • 22
    0454651-067 CLAMP, BUFFER (BLACK)
    CLAMP, BUFFER (BLACK)
  • 23
    0454652 BUFFER, CHAIN
    BUFFER, CHAIN
  • 24
    0454650-067 MOUNT, BUFFER (BLACK)
    MOUNT, BUFFER (BLACK)
