REAR WHEELS для Polaris RANGER RZR 800 EFI I.RED [R09VH76AD] - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    7547237 NUT-FLANGE,TWO PIECE,3/8-24
    NUT-FLANGE,TWO PIECE,3/8-24
  • 2
    1520992-067 WELD-RIM,REAR,12X8,10GA, BLACK
    WELD-RIM,REAR,12X8,10GA, BLACK
  • 3
    1525017 VALVE, RIM
    VALVE, RIM
  • 4
    7661404 PIN, COTTER
    PIN, COTTER
  • 5
    7547337 NUT-M18X1.5,CASTLE,ZINC/YELLOW
    NUT-M18X1.5,CASTLE,ZINC/YELLOW
  • 6
    7555796 WASHER, CONE
    WASHER, CONE
  • 7
    5135113 HUB-WHEEL,REAR,MACH
    HUB-WHEEL,REAR,MACH
  • 8
    7518378 STUD-3/8-24X1.38,PRESS FIT-Z
    STUD-3/8-24X1.38,PRESS FIT-Z
  • 9
    5248250 DISC-BRAKE,REAR,8.625X.188
    DISC-BRAKE,REAR,8.625X.188
  • 10
    7518903 BOLT-3/8-16X3/4-HX/CP/LK-GR5-Y
    BOLT-3/8-16X3/4-HX/CP/LK-GR5-Y
  • 11
    7710440 RING,RETAINING
    RING,RETAINING
  • 12
    3585502 BEARING
    BEARING
  • 13
    5134984 CARRIER-BEARING,WHEEL(MACH)LEFT HAND
    CARRIER-BEARING,WHEEL(MACH)LEFT HAND
  • 13
    5134985 CARRIER-BEARING,WHEEL(MACH)RIGHT HAND
    CARRIER-BEARING,WHEEL(MACH)RIGHT HAND
  • 14
    5413061 TIRE-REAR, 25X10-12
    TIRE-REAR, 25X10-12
