FUEL TANK для Polaris RANGER XP BLACK [R05RD68AB] - 2005 года выпуска
-
№АртикулНазвание
-
11240119 CAP-GAS W/GAUGECAP-GAS W/GAUGE
-
21240213 ASM-FUEL TANK,EFI (INC 4)ASM-FUEL TANK,EFI (INC 4)
-
254360351 ASM-FUEL PUMP AND GASKETASM-FUEL PUMP AND GASKET
-
37518257 SCR-#10-32X1/2SCR-#10-32X1/2
-
42520480 ASM-FUEL PUMP AND GASKETASM-FUEL PUMP AND GASKET
-
57542324 NUT,NYLOKNUT,NYLOK
-
65812231 PAD-FUEL TANK,TOPPAD-FUEL TANK,TOP
-
71013471-067 TANK STRAP, BLACK.TANK STRAP, BLACK.
-
87052095 FITTING,90 DEG,1/8FITTING,90 DEG,1/8
-
98360009-600 LINE,FUEL,1/8 ID,600 CM.LINE,FUEL,1/8 ID,600 CM.
-
105812252 FOIL-TANKFOIL-TANK
-
118450044-153 FUEL LINE, 5 FT.FUEL LINE, 5 FT.
-
122520223 FILTER-FUELFILTER-FUEL
-
137080417 CLAMP,HOSE(SCREW TYPE)CLAMP,HOSE(SCREW TYPE)
-
148360054-90 CONDUIT-FLEX,SLT,5/8,HITEMP-90CONDUIT-FLEX,SLT,5/8,HITEMP-90
-
157080138 CABLE TIECABLE TIE
-
167542153 NUT,NYLOK,FLANGEDNUT,NYLOK,FLANGED
-
175436013 MOUNT-FUEL FILTERMOUNT-FUEL FILTER
-
187517685 SCREWSCREW
-
197670109 CLIP-ROUTINGCLIP-ROUTING
-
207081278 CLIP-ADHESIVE BACK,3/16''CLIP-ADHESIVE BACK,3/16''
-
217515398 SCREWSCREW
-
227515399 SCREWSCREW
-
235247174-067 BRKT-FUEL TANK MNT, BLACKBRKT-FUEL TANK MNT, BLACK
