DIFFERENTIAL - FRONT для Polaris RANGER 6X6 [R04RF50AA] - 2004 года выпуска`

№

Артикул

Название
-

1341344 ASM., FRONT GEARCASE (IF BUILT BEFORE 10/27/03)

ASM., FRONT GEARCASE (IF BUILT BEFORE 10/27/03)

260 ₽
-

1341497 ASM., FRONT GEARCASE (IF BUILT AFTER 10/27/03)

ASM., FRONT GEARCASE (IF BUILT AFTER 10/27/03)

260 ₽
-

3233950 ASM., GEARCASE (INCL. 14,23,24)

ASM., GEARCASE (INCL. 14,23,24)

260 ₽
-

3233954 ASM., CLUTCH (INCLUDES 9-13) (BUILT BEFORE 10/27/03)

ASM., CLUTCH (INCLUDES 9-13) (BUILT BEFORE 10/27/03)

0 ₽
-

3234168 ASM., CLUTCH (INCLUDES 11-13) (IF BUILT AFTER 10/27/03)

ASM., CLUTCH (INCLUDES 11-13) (IF BUILT AFTER 10/27/03)

127 090 ₽
1

3234163 SCREW, SET (IF BUILT AFTER 10/27/03)

SCREW, SET (IF BUILT AFTER 10/27/03)

3 950 ₽
2

3234093 ASM., COVER PLATE (INCLUDES OUTPUT COVER, INSERT, SEAL AND COIL) (BUILT BEFORE 10/27/03)

ASM., COVER PLATE (INCLUDES OUTPUT COVER, INSERT, SEAL AND COIL) (BUILT BEFORE 10/27/03)

260 ₽
2

3234159 ASM., COVER PLATE (INCLUDES OUTPUT COVER, INSERT AND COIL) (IF BUILT AFTER 10/27/03)

ASM., COVER PLATE (INCLUDES OUTPUT COVER, INSERT AND COIL) (IF BUILT AFTER 10/27/03)

93 600 ₽
3

3234164 BUTTON, THRUST (IF BUILT AFTER 10/27/03)

BUTTON, THRUST (IF BUILT AFTER 10/27/03)

1 670 ₽
4

3234165 PLATE, THRUST (IF BUILT AFTER 10/27/03)

PLATE, THRUST (IF BUILT AFTER 10/27/03)

3 120 ₽
5

3233925 KIT, SHIM SET (BUILT BEFORE 10/27/03)

KIT, SHIM SET (BUILT BEFORE 10/27/03)

0 ₽
5

3234161 SHIM, ARMATURE PLATE (IF BUILT AFTER 10/27/03)

SHIM, ARMATURE PLATE (IF BUILT AFTER 10/27/03)

4 580 ₽
6

3233926 BEARING, ROLLER BALL (IF BUILT AFTER 10/27/03)

BEARING, ROLLER BALL (IF BUILT AFTER 10/27/03)

13 520 ₽
7

3233953 ASM., RACE/OUTPUT HUB (INCLUDES 29)

ASM., RACE/OUTPUT HUB (INCLUDES 29)

81 120 ₽
8

3233928 PIN, DOWEL

PIN, DOWEL

3 120 ₽
9

3233932 BEARING, ROLLER BALL (BUILT BEFORE 10/27/03)

BEARING, ROLLER BALL (BUILT BEFORE 10/27/03)

45 760 ₽
10

3233933 CLUTCH HOUSING/RING GEAR (BUILT BEFORE 10/27/03)

CLUTCH HOUSING/RING GEAR (BUILT BEFORE 10/27/03)

130 ₽
10

3234166 CLUTCH HOUSING/RING GEAR (IF BUILT AFTER 10/27/03)

CLUTCH HOUSING/RING GEAR (IF BUILT AFTER 10/27/03)

130 ₽
11

3233949 ASM., ROLL CAGE (INCLUDES SPRING AND ROLL CAGE) (BUILT BEFORE 10/27/03)

ASM., ROLL CAGE (INCLUDES SPRING AND ROLL CAGE) (BUILT BEFORE 10/27/03)

49 920 ₽
11

3234167 ASM., ROLL CAGE (INCLUDES SPRING AND ROLL CAGE) (IF BUILT AFTER 10/27/03)

ASM., ROLL CAGE (INCLUDES SPRING AND ROLL CAGE) (IF BUILT AFTER 10/27/03)

49 920 ₽
11

3233935 SPRING

SPRING

5 620 ₽
12

3233957 KIT, ROLL

KIT, ROLL

26 000 ₽
13

3233934 RING, RETAINING, WIRE FORM

RING, RETAINING, WIRE FORM

4 580 ₽
15

8450003-1525 LINE, FUEL

LINE, FUEL

12 480 ₽
16

4020139 CLIP, ROSEBUD

CLIP, ROSEBUD

630 ₽
17

7080307 CLAMP, HOSE

CLAMP, HOSE

110 ₽
18

3233956 KIT, SEAL KIT (INCLUDES O-RINGS AND SEALS)

KIT, SEAL KIT (INCLUDES O-RINGS AND SEALS)

13 520 ₽
19

3233955 KIT, BOLT

KIT, BOLT

4 990 ₽
20

3233947 COVER, INPUT

COVER, INPUT

12 480 ₽
21

3233945 BEARING, ROLLER BALL (BUILT BEFORE 10/27/03)

BEARING, ROLLER BALL (BUILT BEFORE 10/27/03)

0 ₽
21

3234112 BEARING, ROLLER BALL (IF BUILT AFTER 10/27/03)

BEARING, ROLLER BALL (IF BUILT AFTER 10/27/03)

13 520 ₽
22

3233944 SHAFT, PINION, 11T

SHAFT, PINION, 11T

130 ₽
25

3233942 PLUG, OIL FILL

PLUG, OIL FILL

4 990 ₽
26

7552603 WASHER, SPRING LOCK (BUILT BEFORE 10/27/03)

WASHER, SPRING LOCK (BUILT BEFORE 10/27/03)

110 ₽
27

7512492 SCREW (BUILT BEFORE 10/27/03)

SCREW (BUILT BEFORE 10/27/03)

250 ₽
28

3233951 ASM., DRAIN PLUG

ASM., DRAIN PLUG

6 450 ₽
29

3233929 BEARING, NEEDLE, ROLLER THRUST

BEARING, NEEDLE, ROLLER THRUST

3 540 ₽
30

3234162 RING, RETAINING

RING, RETAINING

3 950 ₽
31

3233924 PLATE ARMATURE

PLATE ARMATURE

19 760 ₽
31

3234160 PLATE ARMATURE

PLATE ARMATURE

19 760 ₽
