FRONT GEARCASE INTERNALS для Polaris RZR 4 900 INTL [Z14XT9EFX] - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    1333105 ASM., GEARCASE, FRONT (INCL. 2-13)
    ASM., GEARCASE, FRONT (INCL. 2-13)
  • 2
    3235168 ASM., COVER OUTPUT
    ASM., COVER OUTPUT
  • 3
    3235169 KIT, HUB ASM. (INCL. BUSHING, HUB SUB. ASM., NYLON SPACER)
    KIT, HUB ASM. (INCL. BUSHING, HUB SUB. ASM., NYLON SPACER)
  • 4
    3235170 KIT, FASTENER (INCL. ALL FASTENERS)
    KIT, FASTENER (INCL. ALL FASTENERS)
  • 5
    3235171 KIT, SEAL REPAIR (INCL. ALL SEALS)
    KIT, SEAL REPAIR (INCL. ALL SEALS)
  • 6
    3234407 PLATE, ARMATURE
    PLATE, ARMATURE
  • 7
    3235174 BEARING, PINION (INCL. ALL BEARINGS)
    BEARING, PINION (INCL. ALL BEARINGS)
  • 8
    3234393 KIT, ROLLER (INCL. COMPLETE SET OF ROLLER
    KIT, ROLLER (INCL. COMPLETE SET OF ROLLER
  • 9
    3235262 ASM., BILLET ROLL CAGE (INCL. ROLL CAGE, SPRING WIRE FOR, H-CLIP)
    ASM., BILLET ROLL CAGE (INCL. ROLL CAGE, SPRING WIRE FOR, H-CLIP)
  • 10
    3235440 KIT, GEARCASE ASM. (INCL. HOSE FITTING, BUSHING, SEAL, GEARCASE, FILL PLUG, DRAIN PLUG)
    KIT, GEARCASE ASM. (INCL. HOSE FITTING, BUSHING, SEAL, GEARCASE, FILL PLUG, DRAIN PLUG)
  • 11
    2203738 PLUG, DRAIN
    PLUG, DRAIN
  • 12
    2203739 PLUG, FILL
    PLUG, FILL
  • 13
    3235441 KIT, RING AND PINION (INCL. PINION, BEARING, INTERNAL SNAP RING, RING GEAR ASM., SHAFT RING)
    KIT, RING AND PINION (INCL. PINION, BEARING, INTERNAL SNAP RING, RING GEAR ASM., SHAFT RING)
  • 14
    3234908 SPRING, TORSION AND RETAINER
    SPRING, TORSION AND RETAINER
