CYLINDER HEAD W/ VALVES для Polaris RZR 170 WHITE [R13VA17AB] - 2013 года выпуска

  • №
    Артикул
    Название
  • 1
    0452405 STUD
    STUD
  • 2
    0454511 ADAPTER, CARBURETOR
    ADAPTER, CARBURETOR
  • 3
    0454512 CLAMP, HOSE
    CLAMP, HOSE
  • 5
    0452459 O-RING
    O-RING
  • 6
    0454513 ASM., MANIFOLD, INTAKE
    ASM., MANIFOLD, INTAKE
  • 7
    0453034 PLUG, SPARK
    PLUG, SPARK
  • 8
    0453449 INSULATOR, MANIFOLD
    INSULATOR, MANIFOLD
  • 9
    0453451 GASKET, MANIFOLD
    GASKET, MANIFOLD
  • 10
    0454848 ASM., CYLINDER, HEAD (INCL. 11-16,30,31)
    ASM., CYLINDER, HEAD (INCL. 11-16,30,31)
  • 11
    0452390 SEAL, VALVE
    SEAL, VALVE
  • 12
    0452388 WASHER, VALVE, SPRING, OUTER
    WASHER, VALVE, SPRING, OUTER
  • 13
    0454515 SPRING, VALVE, OUTER
    SPRING, VALVE, OUTER
  • 14
    0454516 SPRING, VALVE, INNER
    SPRING, VALVE, INNER
  • 15
    0452387 RETAINER, VALVE, SPRING
    RETAINER, VALVE, SPRING
  • 16
    0452389 CLIP, RETAINER
    CLIP, RETAINER
  • 17
    0454517 ASM., CAM SHAFT
    ASM., CAM SHAFT
  • 18
    0454518 BRACKET, CAM SHAFT
    BRACKET, CAM SHAFT
  • 19
    0450268 NUT, FLANGE
    NUT, FLANGE
  • 20
    0452425 WASHER
    WASHER
  • 21
    0452424 NUT, TAPPET ADJUST
    NUT, TAPPET ADJUST
  • 22
    0452423 SCREW, TAPPET ADJUST
    SCREW, TAPPET ADJUST
  • 23
    0454519 SHAFT, EXHAUST, ROCKER ARM
    SHAFT, EXHAUST, ROCKER ARM
  • 24
    0452409 ARM, VALVE, ROCKER
    ARM, VALVE, ROCKER
  • 25
    0452414 ASM., DECOMP. RELEASE
    ASM., DECOMP. RELEASE
  • 26
    0450142 PIN, DOWEL
    PIN, DOWEL
  • 27
    0454520 SHAFT, INTAKE, ROCKER ARM
    SHAFT, INTAKE, ROCKER ARM
  • 28
    0454521 BOLT
    BOLT
  • 29
    0452398 BOLT, STUD
    BOLT, STUD
  • 30
    0454522 VALVE, EXHAUST
    VALVE, EXHAUST
  • 31
    0454523 VALVE, INTAKE
    VALVE, INTAKE
  • 32
    0454524 BOLT, STUD
    BOLT, STUD
  • 33
    0450880 NUT, FLANGE
    NUT, FLANGE
  • 34
    0454365 GASKET, CYLINDER HEAD
    GASKET, CYLINDER HEAD
