HANDLEBAR ASSEMBLY W/ CONTROLS для Polaris 120 INDY - WHITE LIGHTNING [S17WAA1ASA/AEA] - 2017 года выпуска

  • №
    Артикул
    Название
  • 1
    7661624 PIN, RETAINING
    PIN, RETAINING
  • 2
    7710503 RING, RETAINING
    RING, RETAINING
  • 3
    5433528 LEVER, BRAKE
    LEVER, BRAKE
  • 4
    7710401 RING, RETAINING
    RING, RETAINING
  • 5
    7511848 SCREW
    SCREW
  • 6
    2684039 ASM., PAD, HANDLEBAR
    ASM., PAD, HANDLEBAR
  • 7
    5813176 FOAM, HANDLEBAR PAD
    FOAM, HANDLEBAR PAD
  • 8
    1821087-067 HANDLEBAR, ADJUST
    HANDLEBAR, ADJUST
  • 9
    5431096 PLUG, OVERFLOW, RED
    PLUG, OVERFLOW, RED
  • 10
    5430604 BLOCK, ADAPTOR
    BLOCK, ADAPTOR
  • 11
    5433622 INSERT, BRAKE/THROTTLE BLOCK
    INSERT, BRAKE/THROTTLE BLOCK
  • 12
    7661617 RIVET
    RIVET
  • 13
    7555730 WASHER
    WASHER
  • 14
    7512465 SCREW, SOCKET SET
    SCREW, SOCKET SET
  • 15
    5433476 GRIP, HANDLEBAR
    GRIP, HANDLEBAR
  • 16
    7081624 CABLE, BRAKE W/ADJUSTER
    CABLE, BRAKE W/ADJUSTER
  • 17
    7515316 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 18
    1013096-067 BRACE, STEERING POST, LEFT HAND
    BRACE, STEERING POST, LEFT HAND
  • 18
    1013097-067 BRACE, STEERING POST, RIGHT HAND
    BRACE, STEERING POST, RIGHT HAND
  • 19
    7621467 RIVET
    RIVET
  • 20
    5431592 BLOCK, THROTTLE/BRAKE
    BLOCK, THROTTLE/BRAKE
  • 21
    7542122 NUT, NYLOK
    NUT, NYLOK
  • 22
    4013378 SWITCH, AUXILIARY SHUT-OFF
    SWITCH, AUXILIARY SHUT-OFF
  • 23
    1821086-067 POST, STEERING
    POST, STEERING
  • 24
    5433416 BUSHING, STEERING, UPPER
    BUSHING, STEERING, UPPER
  • 25
    5244048 BRACKET, STEERING, UPPER
    BRACKET, STEERING, UPPER
  • 26
    4020139 CLIP, ROSEBUD
    CLIP, ROSEBUD
  • 27
    7542343 NUT, FLANGE
    NUT, FLANGE
  • 28
    7081625 CABLE, THROTTLE
    CABLE, THROTTLE
  • 29
    7555727 WASHER
    WASHER
