SEAT- PASSENGER W/ ARM REST ASSY. для Polaris 550 INDY ADVENTURE 155 [S16CJ5BSL] - 2016 года выпуска

  • №
    Артикул
    Название
  • 1
    2685648 ASM., SEAT, BLACK
    ASM., SEAT, BLACK
  • 1
    2685643 COVER, SEAT, PASSENGER
    COVER, SEAT, PASSENGER
  • 2
    7043990 SPRING, LATCH RIGHT
    SPRING, LATCH RIGHT
  • 3
    5452251 LEVER, LATCH RIGHT
    LEVER, LATCH RIGHT
  • 4
    7518786 BOLT, SHOULDER
    BOLT, SHOULDER
  • 5
    5414695-070 GRIP, HANDLEBAR, LONG, BLACK
    GRIP, HANDLEBAR, LONG, BLACK
  • 6
    7519112 SCREW
    SCREW
  • 7
    5450272 COVER, ARM REST RIGHT
    COVER, ARM REST RIGHT
  • 8
    1021450-458 HAND GRIP RIGHT, MATTE BLACK
    HAND GRIP RIGHT, MATTE BLACK
  • 9
    7547339 NUT, NYLOC
    NUT, NYLOC
  • 10
    5450269 INSERT, PIVOT BUSHING
    INSERT, PIVOT BUSHING
  • 11
    5450268 BUSHING, PIVOT, W/FITTING
    BUSHING, PIVOT, W/FITTING
  • 12
    7518994 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 13
    5450273-070 BASE, SEAT, REAR, BLACK
    BASE, SEAT, REAR, BLACK
  • 14
    7519063 SCREW
    SCREW
  • 15
    5450271 COVER, ARM REST LEFT
    COVER, ARM REST LEFT
  • 16
    1021449-458 HAND GRIP LEFT, BLACK
    HAND GRIP LEFT, BLACK
  • 17
    5257238 SUPPORT, TUBE/LATCH LEFT
    SUPPORT, TUBE/LATCH LEFT
  • 18
    5414655 BUMPER, RUBBER
    BUMPER, RUBBER
  • 19
    7661637 RIVET
    RIVET
  • 20
    5257271 SUPPORT, TUBE/LATCH RIGHT
    SUPPORT, TUBE/LATCH RIGHT
  • 21
    5452250 LEVER, LATCH LEFT
    LEVER, LATCH LEFT
  • 22
    7043989 SPRING, LATCH LEFT
    SPRING, LATCH LEFT
  • 23
    1020067-458 STRUCTURE, BASE, BLACK
    STRUCTURE, BASE, BLACK
  • 24
    7518843 SCREW
    SCREW
  • 25
    5450876 PLUG, RACK
    PLUG, RACK
  • 26
    5412067 BUMPER, RUBBER
    BUMPER, RUBBER
