CONTROL ARMS W/SPINDLE для Polaris 600 SWITCHBACK PRO R ES INTL [S14BS6GEL] - 2014 года выпуска

  • №
    Артикул
    Название
  • 1
    7518917 SCREW
    SCREW
  • 2
    5137700 SHAFT, PIVOT
    SHAFT, PIVOT
  • 3
    5438792 BUSHING, PIVOT
    BUSHING, PIVOT
  • 4
    7547332 NUT, FLANGE, NYLOK
    NUT, FLANGE, NYLOK
  • 5
    2204665-458 KIT, UPPER CONTROL ARM, LEFT HAND, MATTE BLACK
    KIT, UPPER CONTROL ARM, LEFT HAND, MATTE BLACK
  • 5
    2204666-458 KIT, UPPER CONTROL ARM, RIGHT HAND, MATTE BLACK
    KIT, UPPER CONTROL ARM, RIGHT HAND, MATTE BLACK
  • 6
    7061179 BEARING, SPHERICAL, UPPER CONTROL ARM
    BEARING, SPHERICAL, UPPER CONTROL ARM
  • 6
    7710642 RING, RETAINING
    RING, RETAINING
  • 7
    7556212 WASHER
    WASHER
  • 8
    1823801 ASM., SPINDLE, LEFT HAND
    ASM., SPINDLE, LEFT HAND
  • 8
    1823802 ASM., SPINDLE, RIGHT HAND
    ASM., SPINDLE, RIGHT HAND
  • 9
    7547464 NUT, NYLOK
    NUT, NYLOK
  • 10
    5438460 BUSHING, SKI PIVOT
    BUSHING, SKI PIVOT
  • 11
    5136910 BUSHING
    BUSHING
  • 12
    7519015 SCREW
    SCREW
  • 13
    7555806 WASHER
    WASHER
  • 14
    7710539 RING, RETAINING
    RING, RETAINING
  • 15
    2204229 KIT, SPHERICAL BEARING, LOWER
    KIT, SPHERICAL BEARING, LOWER
  • 16
    7547423 NUT, ZOD, NYLOK
    NUT, ZOD, NYLOK
  • 17
    2204663-458 KIT, LOWER CONTROL ARM, LEFT HAND, MATTE BLACK
    KIT, LOWER CONTROL ARM, LEFT HAND, MATTE BLACK
  • 17
    2204664-458 KIT, LOWER CONTROL ARM, RIGHT HAND, MATTE BLACK
    KIT, LOWER CONTROL ARM, RIGHT HAND, MATTE BLACK
  • 18
    5137701 SHAFT, PIVOT, LOWER CONTROL ARM, FRONT
    SHAFT, PIVOT, LOWER CONTROL ARM, FRONT
