COOLING SYSTEM для Polaris WIDETRAK LX [S11SU4BSL] - 2011 года выпуска

  • №
    Артикул
    Название
  • 1
    7512276 BOLT
    BOLT
  • 2
    7558302 WASHER
    WASHER
  • 3
    5430743 CAP, OVERFLOW BOTTLE
    CAP, OVERFLOW BOTTLE
  • 4
    5431096 PLUG, OVERFLOW
    PLUG, OVERFLOW
  • 5
    5810279 GASKET, OVERFLOW CAP
    GASKET, OVERFLOW CAP
  • 6
    7670096 NUT, CHIMNEY
    NUT, CHIMNEY
  • 7
    5431733 BOTTLE W/FITTINGS, OVERFLOW
    BOTTLE W/FITTINGS, OVERFLOW
  • 8
    7661637 RIVET
    RIVET
  • 9
    2511187 ASM., COOLING EXTRUSION, CENTER
    ASM., COOLING EXTRUSION, CENTER
  • 10
    7080844 CLAMP, SPRINGBAND, 35MM
    CLAMP, SPRINGBAND, 35MM
  • 11
    7080841 CLAMP, SPRINGBAND, 27MM
    CLAMP, SPRINGBAND, 27MM
  • 12
    2511257 COOLER, SIDE, LEFT HAND
    COOLER, SIDE, LEFT HAND
  • 12
    2511258 COOLER, SIDE, RIGHT HAND
    COOLER, SIDE, RIGHT HAND
  • 13
    5240555 GUARD, COOLING EXTRUSION
    GUARD, COOLING EXTRUSION
  • 14
    7542122 NUT, NYLOK
    NUT, NYLOK
  • 15
    1240616 ASM., HOSE/CONVOLUTE, RNNGBRD
    ASM., HOSE/CONVOLUTE, RNNGBRD
  • 16
    5413328 HOSE, CALIPER/RUNNING BOARD, LEFT HAND
    HOSE, CALIPER/RUNNING BOARD, LEFT HAND
  • 17
    5411382 HOSE, CLOSEOFF, OUT ENGINE
    HOSE, CLOSEOFF, OUT ENGINE
  • 18
    5241334 BRACKET, OIL TANK, COINED
    BRACKET, OIL TANK, COINED
  • 19
    7080842 CLAMP, SPRINGBAND, 29MM
    CLAMP, SPRINGBAND, 29MM
  • 20
    1240615 ASM., HOSE/CONVOLUTE, FILLER OUT
    ASM., HOSE/CONVOLUTE, FILLER OUT
  • 21
    5413296 HOSE, COOLER TO CALIPER, RIGHT HAND
    HOSE, COOLER TO CALIPER, RIGHT HAND
  • 22
    5433364 FILLER, REMOTE COOLANT
    FILLER, REMOTE COOLANT
  • 23
    2511256 CAP, PRESSURE
    CAP, PRESSURE
  • 24
    7080560 CLAMP, HOSE
    CLAMP, HOSE
  • 25
    7080307 CLAMP, HOSE, LARGE GREEN
    CLAMP, HOSE, LARGE GREEN
  • 26
    8450003-1525 LINE, FUEL
    LINE, FUEL
  • 27
    7052038 VALVE, CHECK
    VALVE, CHECK
  • 28
    2530024 FILTER, COOLANT
    FILTER, COOLANT
  • 29
    4020139 CLIP, ROSEBUD
    CLIP, ROSEBUD
  • 30
    7517298 SCREW
    SCREW
  • 31
    5413223 HOSE, ENGINE OUT/FILLER NECK
    HOSE, ENGINE OUT/FILLER NECK
  • 32
    5241792-067 BRACKET, SILENCER/REMOTE FILLER, BLACK
    BRACKET, SILENCER/REMOTE FILLER, BLACK
  • 33
    5521287-08 CONDUIT, FLEX
    CONDUIT, FLEX
  • 34
    7080138 CABLE TIE
    CABLE TIE
