FUEL TANK для Polaris FS IQ TOURING (S09PT7ES) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    2520798 ASM-FUEL TANK, FS/T, MLD COMP (ALSO ORDER GASKET #13)
    ASM-FUEL TANK, FS/T, MLD COMP (ALSO ORDER GASKET #13)
  • 2
    5435534 CAP-FUEL TANK, ''PREMIUM''
    CAP-FUEL TANK, ''PREMIUM''
  • 3
    7515136 SCREW
    SCREW
  • 4
    5247431 BRKT-SEAT MOUNT
    BRKT-SEAT MOUNT
  • 5
    7542122 NUT-NYLOK
    NUT-NYLOK
  • 6
    7555859 WASHER, FLAT
    WASHER, FLAT
  • 7
    7670154 RETAINER-BOLT, 1/4-20
    RETAINER-BOLT, 1/4-20
  • 8
    7515203 BOLT
    BOLT
  • 9
    5810290 PAD, BATTERY
    PAD, BATTERY
  • 10
    5813100 PAD-RUBBER, 3 X 1.5X .5
    PAD-RUBBER, 3 X 1.5X .5
  • 11
    8450126-72 LINE-VENT, 5/16 ID, 72 CM
    LINE-VENT, 5/16 ID, 72 CM
  • 12
    5436628 NUT-PFA
    NUT-PFA
  • 13
    5413063 GASKET-PFA
    GASKET-PFA
  • 14
    2203302 KIT-PFA, HI CAP, SVC(FS/T)
    KIT-PFA, HI CAP, SVC(FS/T)
