CHASSIS - FRONT для Polaris 800 SWITCHBACK DRAGON EURO (S09PS8EEL) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    1016172-329 STEERING, HOOP (BLACK)
    STEERING, HOOP (BLACK)
  • 2
    7661637 RIVET
    RIVET
  • 3
    7512377 BOLT, CARRIAGE
    BOLT, CARRIAGE
  • 4
    7542343 NUT, FLANGE
    NUT, FLANGE
  • 5
    7517810 SCREW
    SCREW
  • 6
    5135993 SPACER, CHASSIS BRACE
    SPACER, CHASSIS BRACE
  • 7
    5335296-067 BRACE, UPPER, LEFT HAND (BLACK)
    BRACE, UPPER, LEFT HAND (BLACK)
  • 8
    1015381-067 BRACE, UPPER, RIGHT HAND (BLACK)
    BRACE, UPPER, RIGHT HAND (BLACK)
  • 9
    7518070 SCREW
    SCREW
  • 10
    1014820 ASM., PLATE NUT
    ASM., PLATE NUT
  • 11
    1015027 ASM., PLATE NUT
    ASM., PLATE NUT
  • 12
    5249312-067 BRACKET, EXHAUST SOLENOID (BLACK)
    BRACKET, EXHAUST SOLENOID (BLACK)
  • 13
    1016775-329 CROSS MEMBER (BLACK)
    CROSS MEMBER (BLACK)
  • 14
    7518004 SCREW
    SCREW
  • 15
    7558402 WASHER, FLAT
    WASHER, FLAT
