CHASSIS ASSEMBLY TOP для Polaris 600 IQ EURO (S09PB6HEL) - 2009 года выпуска

  • №
    Артикул
    Название
  • 1
    1016172-329 WELD-STRG HOOP,BLK
    WELD-STRG HOOP,BLK
  • 2
    7661637 RIVET,INTERLOCK,Z
    RIVET,INTERLOCK,Z
  • 3
    5411576 DAMPENER-VIBRATION,W/RIBS
    DAMPENER-VIBRATION,W/RIBS
  • 4
    7512377 BOLT,CARRIAGE
    BOLT,CARRIAGE
  • 5
    7542343 NUT,FLANGE
    NUT,FLANGE
  • 6
    7517810 SCR,5/16X24X3/4 TRXPNHD
    SCR,5/16X24X3/4 TRXPNHD
  • 7
    5334676-067 BRACE-UPPER BLACKHD, LEFT HAND, BLACK
    BRACE-UPPER BLACKHD, LEFT HAND, BLACK
  • 7
    1015381-067 WELD-BRACE UPR BLACKD,SPRTRIGHT HAND BLACK
    WELD-BRACE UPR BLACKD,SPRTRIGHT HAND BLACK
  • 8
    5135003 SPACER-CHASSIS BRACE
    SPACER-CHASSIS BRACE
  • 9
    7518070 SCR-5/16-18X1,TRX,GR5,Y
    SCR-5/16-18X1,TRX,GR5,Y
  • 10
    1014820 ASM-PLATE,NUT
    ASM-PLATE,NUT
  • 11
    1015027 ASM-PLATE/NUT
    ASM-PLATE/NUT
  • 12
    5249312-067 BRKT-EXHAUST SOLENOID,600, BLACK
    BRKT-EXHAUST SOLENOID,600, BLACK
  • 13
    1015368-067 WELD-CROSS MEMBER, BLACK
    WELD-CROSS MEMBER, BLACK
  • 14
    5813100 PAD-RUBBER,3 X 1.5X .5
    PAD-RUBBER,3 X 1.5X .5
  • 15
    5813178 PAD-RUBBER 1.88X1.38X.5
    PAD-RUBBER 1.88X1.38X.5
