CONSOLE для Polaris 600 RMK 144 (S08PK8FS) - 2008 года выпуска

  • №
    Артикул
    Название
  • 1
    5411174 O-RING
    O-RING
  • 2
    5435156 NUT-FILLER NECK
    NUT-FILLER NECK
  • 3
    5410611 KEY (SEE NOTE)
    KEY (SEE NOTE)
  • 4
    7547035 NUT, IGNITION
    NUT, IGNITION
  • 5
    2200358 KIT, IGN.SWITCH
    KIT, IGN.SWITCH
  • 6
    7517916 SCR-1/4-20X3/4-TR/TX/TAP-M
    SCR-1/4-20X3/4-TR/TX/TAP-M
  • 7
    7081409 CABLE-CHOKE, RACK, IQ, CR
    CABLE-CHOKE, RACK, IQ, CR
  • 7
    2201439 KIT, CHOKE LEVER REPAIR
    KIT, CHOKE LEVER REPAIR
  • 7
    5432944 NUT, CHOKE
    NUT, CHOKE
  • 7
    7556374 WASHER, INTERLOCK
    WASHER, INTERLOCK
  • 8
    2633499-070 ASM-CONSOLE, MTN 6, BLACK (WARNING DECALS)
    ASM-CONSOLE, MTN 6, BLACK (WARNING DECALS)
  • 9
    7517685 SCREW
    SCREW
  • 10
    7556318 SPACER-.26X.50X.31
    SPACER-.26X.50X.31
  • 11
    7547069 NUTSERT, HEX
    NUTSERT, HEX
  • 12
    7661637 RIVET, INTERLOCK, Z
    RIVET, INTERLOCK, Z
  • 13
    1015643 ASM-SIDE CONSOLE, RIGHT HAND (INCL. 9-11, 15)
    ASM-SIDE CONSOLE, RIGHT HAND (INCL. 9-11, 15)
  • 14
    1015642 ASM-SIDE CONSOLE, LEFT HAND (INCL 9-11, 16)
    ASM-SIDE CONSOLE, LEFT HAND (INCL 9-11, 16)
  • 15
    5813131 FOAM/FIBER-HI TEMP, 1''THK, W/PSA
    FOAM/FIBER-HI TEMP, 1''THK, W/PSA
  • 16
    5813132 FOAM-CONSOLE, LEFT HAND, W/PSA
    FOAM-CONSOLE, LEFT HAND, W/PSA
