CRANKSHAFT ASSY. W/ PISTON для Polaris 120 DRAGON (BLACK) (S08WB1AEA) - 2008 года выпуска`
-
№АртикулНазвание
-
13088203 SET, PISTON, RING, STANDARDSET, PISTON, RING, STANDARD
-
13088204 SET, PISTON, RING, .010''/.25MM O/SSET, PISTON, RING, .010''/.25MM O/S
-
13088205 SET, PISTON, RING, .020''/.50MM O/SSET, PISTON, RING, .020''/.50MM O/S
-
23086553 CLIP, PISTON PINCLIP, PISTON PIN
-
33086546 PIN, PISTONPIN, PISTON
-
43086969 SET, PISTON, STANDARD (INCL. 2)SET, PISTON, STANDARD (INCL. 2)
-
43086970 SET, PISTON, .010''/.25MM O/S (INCL. 2)SET, PISTON, .010''/.25MM O/S (INCL. 2)
-
43086971 SET, PISTON, .020''/.50MM O/S (INCL. 2)SET, PISTON, .020''/.50MM O/S (INCL. 2)
-
53086544 ROD, CONNECTING (INCL. 8)ROD, CONNECTING (INCL. 8)
-
63240294 NUTNUT
-
73086540 WASHER, SPRINGWASHER, SPRING
-
83086545 BOLT, CONNECTING RODBOLT, CONNECTING ROD
-
93086537 SPACER(0.6)SPACER(0.6)
-
93086538 SPACER(0.8)SPACER(0.8)
-
93086539 SPACER(1.0)SPACER(1.0)
-
103086949 CRANKSHAFTCRANKSHAFT
-
113086536 KEY, WOODRUFFKEY, WOODRUFF
